CW content
The KKS-1 has four CW modes.
We can change each mode by sending a command from the ground station.
Mode0: Immediately after turning on the power
Mode1: After receiving the command
Mode2: Immediately after the command reception
Mode3: Safe mode
Figure 3-1.Mode0（Immediately after turning on the power）
No Overview Submissions Actual
1 Greetings 1 HELLO THIS IS KKS-1 ○
2 School Address 2 8-52-11 MINAMI-SENJYU ARAKAWA-KU TOKYO-TO JAPAN ○
3 School Name 3 Tokyo Metropolitan College of Industrial Technology ○
4 School HP 4 http://www.kouku-k.ac.jp/~kks-1 ○
5 KKS-1 Call sign 5 JQ1YYY ○
6 KKS-1Ilnternal time 6 [yy]/[mm]/[dd] [hh]:[mm]:[ss] ○
Figure 3-2.Mode1（After receiving the command）
No Text
1 1 HELLO THIS IS KKS‐1
2 2 [Battery voltage] [Discharge current of battery] [Charge current of battery] [Bus voltage]
3 3 [5V voltage for transmitter] [5V voltage for circuit] [12V voltage] [5V current for transmitter] [5V current for circuit] [12V current] [Mission circuit current]
4 4 [Satellite temperature ] [No.1 thermistor output of transmitter ] [No.2 thermistor output of transmitter] [Battery temperature]
5 5 [solar battery output from X＋ side] [Y＋ side] [Z＋side] [X－side] [Y－side] [Z－side]
6 6 [Number of counts of SEL incidence] [SEL incidence time]
7 7 [yy]/[mm]/[dd] [hh]:[mm]:[ss]
8 8 [yy]/[mm]/[dd] [hh]:[mm]:[ss]
9 9 R [UL latest command] [Current status of processing]
Figure 3-3.Mode2（Immediately after the command reception）
No Text
1 R [UL latest command] [Current status of processing]
Figure 3-4.Mode3（Safe mode）
No Text
1 1 HELLO THIS IS KKS‐1
2 2 JQ1YYY
3 3 [Battery voltage] [Discharge current of battery] [Charge current of battery] [Bus voltage]
4 4 [yy]/[mm]/[dd] [hh]:[mm]:[ss]
4．FM content
These are test data of the KKS-1.
We will update detailed information on FM content of KKS-1.
Figure 4.Test data
No Text
I hope the following year will be another wonderful one.
