美軍無線電器材 的 BC 系列
SIGNAL CORPS BC- (Basic Component) DIRECTORY
NOTES:
Most WW-2 equipment poweredby 24-28 VDC, or 115 V 400-800 Hz AC
* = two or more variations exist
P/O = Part Of
R/B = Replaced By
U/W = Used (in association) With
In early sets, C-* designationsrefer to Coils and Transformers
BC-Number
Description andTypical Usage
TM/TO No.
Date
BC-1
Box
Early Boxes could be equipment parts chests or
BC-2
Box
contain an entire radio set....
BC-3
Box
BC-4
Box
BC-5
Chest for TE-51 WeldingEquipment
(used in both World Wars)
SIG-5, 1947, lists BC-5 U/W MK-4E/TRC-1Maintenance Equipment.
FM 24-19, 1966, has BC-5U/W GR-8 Sound Ranging Set
29x18x12", 130 lbs
BC-6
Box
BC-7
CW Radio (R-T), P/OSCR-127
550-1100 M 4
VT-3, 3 VT-3
JK-3
BC-8
Aircraft Receiver-Amp, 150-500KC
6 tubes
BC-9A
Radio Set, 4100-4400 KC
CO-58
BC-10
Aircraft Interphone P/O SCR-57(for pilot and observer/gunner)
BC-10A
Improved BC-10 (has side-tone circuit)
BC-11A
Aircraft Radio AM
Rcvr 500-1580, Xmtr 600-1500 KC
P/O SCR-68A
BC-12
Aircraft Receiver, 350-2000 KC
P/O SCR-59,A
BC-13A
Radio Set; Rcvr 500-1500, Xmtr 775-1250 KC
P/O SCR-67A
BC-14
Receiver, 500-1500 KC
French design Xtal-set (opt. BC-19,A VT det.)
C/O BA-4, DC-1 (galena), P-11 Headset, ST-5Strap, TL-2
P/O SCR-54
built by DeForest, Liberty Electric and others
BC-14A
Receiver, P/O SCR-54A
(same asabove, with internal test buzzer)
BC-15
Aircraft Xmitter, 1-3 MC
quenched gap
P/OSCR-65
BC-15A
Aircraft Xmitter
P/O SCR-65A
as above,with minor improvements
BC-16
Trench Telegraph P/OSCR-71
(600-1300 cps buzzer)
BC-17
Trench Telegraph P/OSCR-72
like above, with four VT-1 tubes
BC-18,A
Xmitter P/OSCR-74,A
10 volt, 100 watt spark coil F= ??
BC-19,A
DT-3 Detector (one VT-1tube)
U/W BC-14
P/O SCR-54
BC-19A
Detector, P/O DT-3A
similiar to above
BC-20
Aircraft Receiver, 350-2000KC
3 VT-1 tubes
P/O SCR-75
BC-21
Trench Telegraph, P/OSCR-76
combines SCR-71 and 72 in one unit
BC-21A
Trench Telegraph, P/O SCR-76A
improved version of above set
BC-22
Radio Set, (firstWalkie-Talkie: F = ??)
BC-23
Receiver, 175-500 KC
Autodyne type, with one VT-1
P/O SCR-70
BC-24
Radio Set, 800-1000 KC, 250 Wquenched gap
P/O SCR-49
BC-25
Box for PE-7 Power Supply
U/W DM-1 Dynamotor
P/O SCR-78,79,130
BC-26
Carrying Chest for SCR-54-A
BC-27
....
BC-28
....
BC-29
Amplifier
BC-30
Dry Battery Test SetCase:
Voltmeter I-3 and Ammeter I-4
BC-31
Leather Carrying Case, forVoltmeters I-4, I-6. Ammeters I-7, I-8, I-9
BC-32*
Radio Set, 273-600 KC
RS-30 (3.6 ohm)
3 VT rcvr, 1 VT xmtr
P/O SCR-79
BC-33
BatteryBox
P/O SCR-78*
BC-34
Radio Set Box
BC-35
Chest, for packing type A-6Antenna Equipment
BC-36
Receiver (Type D ReceivingBox), 125-1000 KC
xtal det
P/OSCR-49
BC-37
Wavemeter, 125-2000 KC
P/O SCR-61
BC-38
Radio Set
P/O SCR-77 "Short Wave"
F = ??
BC-39
Radio Set, 273-600 KC
P/O SCR-78,A
3 VT rcvr, 1 VT xmtr
BC-40
Wavemeter, 273-600 KC
P/O SCR-95
BC-41
Tester for VT-1 typetubes
P/O RE-10
VT-1 oscillator
WE Type 5730
BC-42
Radio Set Box
BC-43
Carrying Chest
P/O SCR-79*
BC-44
AF Amplifier
P/O RC-3, RC-10
U/W SCR-72* Aircraft Receiver
BC-45
Radio Set
P/O SCR-99
BC-46
Auxiliary Transmitter
BC-47
Radio Set
BC-48
Box
BC-49
Wavemeter
U/W SCR-99
BC-50
Wavemeter
BC-51
Case
BC-52
Radio Set Box
BC-53
Radio Set
BC-54
Chest
BC-55
Transmitter
BC-56
Aircraft Interphone
BC-57
Testing Buzzer
BC-58
Chest
BC-59
Amplifier
P/O SCR-84
BC-60
Switch Box
P/O SCR-84
BC-61
Box
P/O SCR-84
BC-62
Box, for PE-19
P/O SCR-84
BC-63
Test Equipment
BC-65
....
BC-66
Box
BC-67
....
BC-68
Test Unit
BC-69
Detector and AF AmplifierP/O SCR-121-A
BC-70
Wavemeter
BC-71
Telephone Box
BC-72
BatteryBox P/O SCR-112
BC-73
Switch Box
SW-42 DPDT Knife Sw.
BC-74
Switch Box
SW-42 DPDT Knife Sw.
BC-75
Tool Chest
BC-76
Tool Chest
BC-77
Chest for TE-6 GeneralPurpose Tool Set
inc BZ-5
BC-77-A
Line Unit
BC-78
CBx for Signal Lamp
BC-79
Chest for EE-17, (StrombosHorn Gas Alarm) compressed air tanks (2)
BC-80
Chest for EE-17, Strombos HornGas Alarm unit
BC-81
CBx for EE-6-A Signal Lamp(leather box with J-35 Key)
BC-82
BatteryCase
BC-83
Box
BC-84
CBx for EE-6 Signal Lamp
(leather box w 4 BA-11 and J-34 Key)
BC-85
Utility Box for EE-6 SignalLamp
BC-86*
Transmitter, 600-1000 KCTM-5/144, RS-50(3.6 ohm) SW-98
P/OSCR-109,159
BC-87
Box for TE-26 SolderingEquipment
BC-87-A
Box, containing RFChoke C-226
BC-88
Tool Chest
BC-89
Tool Chest
BC-90
Chest for TE-14 Carpenter ToolSet
BC-91
Tool Chest
BC-92
CBx
BC-93
Tool Chest
BC-94
Switch Box
BC-95
Switch Box
BC-96
Switch Box
SW-42 DPDT Knife Sw.
BC-97
Chest for EE-34 equipment
BC-98*
Receiver, 273-1000 KC
RS-31 (10K,tapped), TM-5/144
P/O SCR-109, 159
BC-99
Switch Box
BC-100
Amplifier
BC-101*
Amplifier
U/W JK-3
BC-102
Distribution Panel Box
BC-103
Amplifier
BC-104
Receiver, heterodyne type,100-300 KC
BC-105
Amplifier
BC-106
....
BC-107
Radio Set
BC-108
....
BC-109
....
BC-110
Aircraft Transmitter, 250-350KC
1 VT-2 and 5 VT-4
P/O SCR-135
BC-111
....
BC-112
....
BC-113
Control Unit
BC-114
Aircraft Xmitter, 400-850KC
VT-2,3 VT-4.
C-67, GN-33*, RS-74,75,76
P/O SCR-134
BC-115
Tuner (receiver) 250-1500KC
VT-5
R/B BC-152
P/O SCR-133,134,135
BC-116
RF Amplifier
7 VT-5 tubes
U/WBC-115
BC-117
Switch Box
BC-118A
Amplifier, RF-AF, 40-1000 KC
6 VT-5 tubes
CH-2 Chest
P/O SCR-132
BC-119
CBx for BC-114 Xmtr
P/O SCR-134
BC-120
CBx
P/OSCR-135
BC-121
CBx
P/O SCR-135
BC-122
Transmitter, 330-860 KC.
VT-2, 3 VT-4: CN-17,18,19, CO-115, IS-10,45,
IS-98,106, MG-4, RS-68,77,80
P/O SCR-136
BC-123
Interphone Control Box
RS-52 (22 ohm)
P/O SCR-155
BC-124
....
BC-125
....
BC-126
Jack Box
RS-52
P/O SCR-155
BC-127
Transmitter, 150-350 KC
4 VT-4B, 22
BK-2, GN-33*, IS-45,78,107,114,
JK-23, RS-54,56,60,86, SW-95,97
P/O SCR-132
BC-128
Aircraft Battery Box
(Three BA-2 Batts in series for 60 V)
BC-129
Aircraft Xmitter, 850-1500KC
3 VT-2
RS-53,71
P/O SCR-133
c 1925
BC-130
Control Box
IS-95, JK-23
P/O SCR-133
BC-131
Regen. Receiver, 40-1000KC
S/T IP-501, SE-1420
1 VT-5
FT-65B
BC-132
Control Box forMotor-Generator GN-31
BC-133
....
BC-134
....
BC-135
....
BC-136
CBx
BC-137
Receiver, 330-860 KC
4 VT-5 tubes
P/OSCR-136
BC-138
Antenna Tuner for receiverRF amp.
100-1000 KC
P/OSCR-132
BC-139
Transmitter, 550-110 KC
S/T BC-127
BC-140
Filter
BC-141
Amplifier
BC-142
Remote Control Box for SCR-132and similar sets.
BC-143
....
BC-144
Receiver
4 VT-5 tubes
Wireless Speciality Apparatus Co.
P/O SCR-162
BC-145
Transmitter (see BC-147)
BC-146
Receiver
BC-147
Transmitter, 4-4.5, 8-9 and12-13.5 MC. .5 KW
imp. BC-145
BC-148
Radio Set, 3960-4360 KC
BK-5, CO-63-67, I-54, JK-3, RS-94
P/O SCR-131
BC-149
....
BC-150
Wavemeter, 100-2000 KC
BC-151
Aircraft Radio, 4370-5100KC
BK-5, CO-63,64,65,66,67, I-54, JK-3,
RS-94
P/OSCR-161
BC-*-152
Receiver, 250-1500 KC
8 VT-5 tubes
P/OSCR-133,135
BC-*-153
Wavemeter, 75-1500 KC
U/W BA-27, IS-69
replaces SCR-60-C, 125-A
BC-154
Radio Beacon Transmitter
...KC
2 KW. built at ARL
BC-*-155 Receiver, 1.2-25 MC
4-tube, TRF
6 VDC
U/W RA-7 Batt. Eliminator
BC-156
Radio Set, 2-3 MC
BK-5, CO-63-67, JK-3, I-54, RS-92,94
P/O SCR-171
BC-157* Radio Set, 2.3-2.7 MC
BK-4,6, C-85-89,92,117,118 Coils, CO-61,69,80,
IN-85, IS-56,85, JK-28, RS-92,93, SW-101,102
P/O SCR-163
BC-158
Receiver, like BC-155 plus1000-2500 KC
P/O SCR-175,176
BC-159
Receiver, 15-1000 KC
P/O SCR-175,176
BC-160
Relay Unit
(Collins)
P/OSCR-175,176
BC-161
Boehme
Model 1-G Recorder, inked paper
P/O SCR-175,176
BC-162
....
BC-*-163
Amplifier
BC-164
Balloon Xmitter, appx 2.4MC
UV-199tube
P/O SCR 170,173
BC-165
....
BC-166
....
BC-*-167
Receiver
BC-168
Radio Tuner
BC-*-169
Radio Tuner
BC-*-170
Radio Tuner
BC-171
Receiver
BC-172
....
BC-GL-173
Xmitter,
RCA type ET-3655C
for Armytransport ships
BC-174
....
BC-175
Rcvr, 2.1-2.9 MC (TRF) 6VDC
C-91-95, IS-116, JK-3, RS=98
P/OSCR-189,190
BC-176*
Xmtr, 2.2-2.6 MC, 7.5W
VT-25,50
BC-206, BK-6, C-90,96,103 Coils,
CD-214,243,351, JK-28,31, PE-48, RS-112,113,SW-104
P/O SCR-189,209
BC-177
CBx for BC-176
JK-28, SW-103
"
"
BC-178
Radio Set, powered by drycells (90 V B-Bat)
BC-*-179
Rcvr, 200-400 KC and2.5-7.7 MC
C-156, CS-44, FT-99,MC-154-157,
P/OSCR-183,192
BC-*-180
Aircraft Xmtr, 3-3.8 or6.2-7.7 MC
FT-100, IS-84
P/OSCR-*-183
BC-181
CBx for BC-179
P/O SCR-183*,192
BC-*-182
CBx (on FT-118)
P/O SCR-*-183
BC-*-183
Aircraft Radio Set
on FT-103
P/O SCR-183
BC-184
....
BC-185
Xmitter
RA-8
BC-186
Receiver
2.4-3.7 MC
C-134,135,IS-117, JK-30
P/O SCR-178,179
BC-187* Xmitter 2.4-3.7 MC
TM-139
U/W BC-188*
"
"
"
BC-188* Modulator
BZ-5, IS-119,JK-23, RS-88, TM-139
"
"
"
BC-189* Rcvr, .15-13 MC (S-Het) U/W BC-206, BK-8, C-142-151 (Coil Sets)CD-242,
CD-371, JK-30, FT-129, RS-143,SW-110
P/O SCR-177,180,188,193,209,210
BC-190
....
BC-AA-191
Predecessor of BC-191,evolved from GE Co. RT-76A
1935
BC-*-191* Xmitter, 200-12000 KC; BK-16,CD-288,290,292,346,358,359,410,472,1087
FT-111/115,151, I-122,IS-22,89, PE-49*, RC-47, SO-39,44,54, SW-106,
Tuning Units TU-5 throughTU-10
Antenna Tuner BC-306 on FT-142
P/OSCR-177,185,187,188,193
12 VDC (BC-375*is 24 V)
11-600,800,4017
BC-AA-192
Control Box
U/WBC-AA-191, CD-204,209, FT-112
P/OSCR-193
BC-AB-192
Control Box
on FT-192
U/W SCR-AA,AB-186
BC-AA-193
Ant Tuning Unit
on FT-108, IS-88
U/W RT-76-A/BC-AA-191
BC-AA-194
Ant Tuning Unit
on FT-108, IS-88
U/W RT-76-A/BC-AA-191
BC-195
....
BC-*-196
Ant. Relay
U/W BC-*-191, CD-204,209, FT-116
P/O SCR-187,193
BC-*-197* Monitor Rcvr, 100-1000 KC
TRF
CD-186,187 RA-11/16D
P/O SCR-243
BC-*-198
Ant. Relay
U/WCD-137*, FT-118
P/O SCR-*-183
BC-*-199
Receiver
200-400 KC, 2.5-7.7 MC
C-127-131,156,157, CS-44 FT-99,
MC-154-157,
P/OSCR-*-183
BC-*-200
Xmitter, 6.2-7.7 MC
3 VT-25, VT-52
C-140, FT-100, IS-84
P/O SCR-183
BC-*-201
CBx
P/O SCR-*-183
BC-*-202
CBx
P/O SCR-*-183
BC-203
....
BC-AA-204
Antenna Tuner
FT-108, IS-88
U/W RT-76-A/BC-AA-191
P/O SCR-193
BC-205*
Loop Tuning Unit
3 plugs and 3 binding posts, 0-100 Dial
BC-206A
Control Box
U/W BC-176A,BC-312
CD-243,348, IS-85, RS-58, SW-144
P/OSCR-209*
BC-207-T2
Transmitter
BC-208
Antenna Relay Unit, for BC-191
BC-*-209
Amplifier
400-1500 KC
U/W IS-122, TU-AA-23,24,
PE-*-50Gas Gen
BC-210
Weather Receiver (NationalR-10)
U/W FM-17, RA-9
P/O RC-13
BC-211
cancelled
BC-212-
Interphone Amp, 1 39/44tube
SW-121
P/O RC-15
BC-212-B
Interphone Amp, 2 6C5 tubes
P/ORC-27
BC-212-*
Interphone Amp.
Choke C-206, RS-182,183,185,186
P/O RC-27
BC-213-*
Interphone JBx
SW-122,123
P/O RC-13,15A
BC-214*
Control Box
on FT-134
P/OSCR-177,178,180,188,189,197
BC-215
Control Box
on FT-417?
U/WBC-AA-188, SCR-*-183
BC-216
Microphone Amp. 6F7 and 39/44,
CD-198,FT-144
U/W SCR-183
P/O RC-19
BC-217-T2
Ant. Tuning Unit
200-300 KC
P/O SCR-204-T
BC-218
....
BC-*-219
Aircraft Rcvr, .15-12.5MC
C-128,129,133, FT-99
P/O SCR-183,185,187
BC-220
....
BC-221
(36+ models)
Freq-Meter, .125-20 MC
3 tubes
P/O SCR-211
BC-222*
Field Set, 28-52 MC, 2 Ch.2 W. AN-29,30 IS-121 TM 11-238
P/OSCR-194
BC-223*
Xmitter, 2-5.25 MC. 30 WCW, 10 W AM
BK-16, CD-342,356,357,FT-173,
RS-158,202,204,205,261,273,SW-132,133,189
P/O SCR-245*
BC-224*
Receiver, .2-.5 and 1.5-18MC (12 V version of BC-348) 8-9 tubes
FT-154, BD-94-*, CO-150,CD-647, DM-24*
P/O SCR-187,238
TO 08-10-24
BC-225*
Receiver, .2-8 MC, 4 bands,7 tubes
DM-22*, FT-180
P/O SCR-240
BC-226*
CBx
P/O SCR-240
BC-227*
Receiver, 2.1-3.1 MC
C-91, JK-30
P/OSCR-203
BC-228*
Transmitter
2.1-3.1 MC
2 VT-25,50
BK-6, C-103,CD-202,228, IS-119,
IS-120, JK-31, RS-113,236
P/O SCR-203
BC-*-229
Aircraft Rcvr,.2-.4/2.5-7.7 MC
6 tubes, 12 V,
C-266,270-272,275,
FT-99
P/OSCR-*-183
BC-*-230
Xmitter, 2.5-7.7 MC, 20W
12 VDC,
C-182-185,198,200,216-220, CS-47,
DC-10, FT-100
P/OSCR-*-183
BC-*-231
CBx
U/W BC-AL-229 Rcvr
P/OSCR-*-183
BC-AE-231
CBx
P/O SCR-A*-183,-*-185,-*-87
BC-AR-231
CBx
P/OSCR-AR-183,-AR-283
BC-*-232
CBx
(on FT-118)
U/W BC-AL-230 Xmitter
P/O SCR-*-183
BC-233
Radio Compass
U/W CD-191, LP-12, PL-91
P/O SCR-186-T6
BC-234
....
BC-235
CBx
RS-58, TM-176, SW-103
P/OSCR-203
BC-236
SwBx
P/OSCR-183
BC-237
....
BC-238
....
BC-239
....
BC-240
....
BC-242
....
BC-245
Radio Compass Monitor
CA-359
P/O RC-25
BC-245* Radio Set
SW-189
BC-250
....
BC-252
Receiver
BC-255
Receiver
BC-260
....
BC-267
Interphone Amp.
DM-25
BC-270
Xmitter, 300 W
BC-275
....
BC-280
....
BC-284A
Receiver
TM11-275
BC-299
Receiver
12VDC version of SCR-283
P/OSCR-AR-183
BC-300
....
BC-301
Mrkr Beacon Rcvr, 75 MC, 1 6F7
BK-15, FT-161, MC-169, SW-134
P/ORC-20
BC-302
Beacon Transmitter, 75 MC
VT-64
U/W BC-303,BC-902, C-213, GS-9,
IS-123,124, SW-135
P/O SCR-241
BC-303*
Transmitter, 75 MC, 11tubes
FT-263*
P/O SCR-241
TO08-10-96
9-42
BC-304*
Interphone CBx
RS-191, SW-124,126
BC-305*
Interphone CBx
SW-125
BC-306*
Antenna Tuning Unit,150-800 KC
FT-142
U/W BC-191/375
P/O SCR-177
BC-307*
Transmitter
BD-86, FT-156,157,167
P/O SCR-238,248
BC-308*
Control Box
GE Co.
P/OSCR-238,248
BC-309
Control Box
U/WBC-191/375, CD-295
P/OSCR-187A,193
BC-310*
Radio Compass, 150-1500 KC,15 tubes, CD-311*, DM-18*,20, FT-145*,
I-70, MO-4
P/OSCR-242
BC-311
Receiver CBx
U/W Test Box BX-18-A, P/O SCR-342
BC-312*
Receiver, 1.5-18 MC
S/T BC-342
12/24 VDC
U/W BC-206A, Ant. AS-81/GR,
BB-50, CD-275, CG-52,57/GR,CD-276,277,278,284,312,317,339,342,348,
CO-38, DM-17*,21,FT-162,176,389, MC-269, RS-178,223,267,268, SW-119
P/OSCR-177,188,193,197,209,210,245
TO08-10-28
1940
BC-313
Frequency Meter
CS-50 Case
BC-314*
Receiver, 150-1500 KC, 9tubes
DM-21
P/O SCR-177
TM 11-850
BC-315
Transmitter, 2-18 MC, A1, 2,3
400 W
17 tubes
RS-80
WE Co.
BC-316
Antenna Tuning Unit
BC-317
Oscillator
IS-126, SW-129
BC-318
Marker Beacon IndicatorSwitch Box SW-134
P/O RC-20*
BC-319*
Transmitter, 4-13.4MC
300 W
14 tubes, inc 6 837
IS-7,149Ammeters
BC-320
Receiver
BC-321
Control Box U/W BC-312,CD-278, CO-173
P/OSCR-193,245
BC-322
Field Set, 52-66 MC, AN-30*,IS-121, RS-158
S/T BC-222 P/OSCR-194,195
BC-323
....
BC-324
Receiver, 12 V version ofBC-348
used RA-20 for AC operation
BC-325*
Transmitter, 1.5-18 MC,400/100 W
FU-32,IS-132,140,141,152,155,157,
IS-158*
P/O SCR-197
TM 11-805
BC-326*
Switch Box
RS-254SW-135
U/W M-185 Map Lamp
P/O SCR-*-183,283
BC-327
Radio and Intercom ControlBox
P/O RC-27,35 Interphone Sets
BC-328
Transmitter, using 3 837tetrodes and 1 each 851 and 860 tubes
BC-329*
Transmitter, 190-410 KC,AM, 25 W 14 tubes (T-27L,T-4/FRC)
FU-26
U/W MC-576 (BC-329-J, 200-550KC), RM-6*
TM 11-817
BC-330
Transmitter
three 837 and 14 other tubes
BC-331
RF Coupling Unit
BC-332
Antenna Tuning Unit
BC-333
....
BC-334
Interphone Master CBx
U/WFT-168, SW-136
P/O RC-26,27,34,35
BC-335
Aircraft Interphone Box
(P and M jacks + VC)
P/O RC-26,27,34,35
BC-336
....
BC-337
Transmitter
BC-338
Transmitter, 3-8 MC
FT-179*,I-71*
P/O SCR-240
BC-339*
Transmitter, .4-26.5 MC, 1KW, AM
IS-131, O-5/FR, RA-22
TM 11-836
BC-340*
RF Amp, 4-27 MC, 10KW
U/W RA-22, RU-2
U/W BC-339, AN/FRA-2
11-801
BC-341*
Marker Beacon Rcvr 62-80 MC12C8,12SQ7
FT-161
P/O RC-39A
TO 08-10-89
BC-342*
Receiver, 1.5-18 MC (115VAC version BC-312 and R-336/GRC-26) 10 tubes
FT-162,389, MC-269,RS-178
P/O SCR-197,277,299,399,499,AN/MRC-1, MRQ-2, TRQ-1
TO 08-10-28
BC-343
Antenna Tuning Unit U/EBC-337
P/O SCR-250
BC-344*
Receiver, 150-1500 KC,(115 VAC BC-314)
TM 11-850, 4002
BC-345
Audio Filter Control Box
U/W FL-5-E, SW-138
P/O RC-32, 198
BC-346
Transmitter
RS-231
BC-347*
Interphone Amp. (6F8) RS-226,283
P/O RC-34,35,36,47,51
TO 08-5-71,74
1943
BC-348(A-R) Famous Air-Ground Rcvr 200-500 KC and 1.5-18 MC
U/W
DM-24*/28*,
FT-154*
P/O SCR-260,287, ARR-11*
TM 11-692*, TO 08-10-25
1942
BC-349
Transmitter
P/O SCR-260
BC-350
....
BC-351
CBx
P/O SCR-261
BC-352
Receiver, .2-8 MC
7 tubes
DM-23-A, FT-180
P/OSCR-261
BC-353
Transmitter
.2-8 MC
7 tubes
FT-179, I-71*
P/O SCR-261
BC-354
Radio Compass LocatorMonitor
1 6H6
FT-190
P/O RC-25
BC-355
Marker Beacon Monitor
70-80 MC
1 6H6
FT-191
P/ORC-25
BC-356*
AF Monitor
60-1100 C
(41, 80and 2 6R7)
FT-193
P/O RC-25
BC-357*
Marker Beacon Rcvr,62-80 MC
12C8,12SQ7 FT-161
P/O RC-43
TO 08-10-89
BC-358
Transmitter
BC-359
Receiver
BC-360
Audio Amplifier
BC-361
Interphone Control Box
U/W BK-18,19 Relays
BC-362
Interphone Control Box
BC-363
Switch Box
BC-364
Loudspeaker ControlBox
RS-233 L-Pad
BC-365*
Transmitter, 155-550 KC,CW, FSK
350 W
RL-3, RM-10*
TM11-828
1944
BC-366*
Aircraft Interphone ControlBox
5-position SW-145
P/O RC-36,45
BC-367
Interphone Amp. 12 VDC
C-279, DM-25, RS-243, SW-157
2 VT-107 (6V6)
P/ORC-37,38,53,66,99
TM11-702
BC-368
CBx
SW-142
P/O RC-38 Tank Interphone(commander-radio op.)
BC-369
CBx
P/O RC-38 Tank Interphone (driver)
BC-370
Interphone JBx
P/O RC-37, Command Car and RC-38 Tank andRC-48
BC-371
Xmitter
BC-372
Xmitter, 1.5-12.5 MC
U/W PE-72 12 V
P/OSCR-187-B
BC-373*
LF Radio Compass Rcvr,13 tubes
DM-29*, LP-17-A
P/O SCR-246
BC-374*
CBx
U/W I-74 tuning meter
P/OSCR-246
BC-375*
Xmitter, 200-500 KC,1.5-12.5 MC, 100 W
24 V version ofBC-191, used
same TUs, FT-151*
P/OSCR-177,287, etc.
TO 08-10-6,65
1942
BC-376*
Marker Beacon TestOsc, 75 MC, w 400,1300,3000 mod.
4tubes, BA-35,36
I-195-E
U/W BE-67 Test Ind.
P/O IE-76
TO 08-10-113
1942
BC-377
Interphone Amplifier
BC-378
Jack Box
P/O RC-53 Tank Interphone (driver)
TM 11-700
1942
BC-379
Jack Box
P/ORC-53 Tank Interphone (gunner)
TM11-700
1942
BC-380
Meteorogical Receiver,
U/W ML-128 Meteorgraph
BC-381
Transmitter
BC-382
Frequency Meter
BC-383*
Radio Compass, 13tubes
DM-39*
P/O SCR-276
BC-384
Jack Box
BC-385
Jack Box
BC-386
CBx
P/O RC-37-T2
BC-387
CBx
BC-388
Interphone Amplifier
P/O RC-37-T112
Used in M1A1 combat vehicle
BC-389
Modulator
BC-390
Remote Control ChannelSelector Unit
JB-24
P/O RC-31
BC-391
Test Unit
BC-392*
Transmitter
5.5-7 MC
power ?
TM11-817A
BC-393
Transmitter, 5.5-7 MC
P/O SCR-273A
BC-394
Receiver, 200-400 KC
DM-26*
P/OSCR-274A,B
BC-395
Receiver, 4.2-7 MC
DM-26*
"
"
BC-396
Modulator
DM-27*
"
"
BC-397
Control Box
"
"
BC-398
Control Box
P/O SCR-283
BC-399
Antenna Relay
U/W FT-214
"
"
BC-400*
Transmitter, 75 MC
15 tubes
P/ORC-20 Marker Beacon Set
TM 11-2607
BC-401*
Transmitter, 2-18 MC,A1,2,3
400 W
P/ORA-30, RM-11
abt 40 tubes
BC-402*
Keying Unit, 105 MC
P/OSCR-270, 271 Radars
BC-403*
Oscilloscope, 5BP1/4
U/W I-144,146, CD-710, SW-127
P/O SCR-270,271
BC-404*
Receiver, 200-220 MC
P/O P/O SCR-270-271 Radars
TM 11-1114
BC-405*
Xmitter, 105 MC
(M-272,73,74, MC-227 cooling) SW-155
P/O SCR-270,271
BC-406
Receiver, 200-210 MC
15 tube
P/OSCR-268 Radar
"First ArmyRadar"
BC-407*
Power ring-oscillator 205MC
P/O SCR-268 Radar
used 8 100TS tubes
BC-407A
same, using 16 100TS tubes for peak outputof 100 KW
BC-*-408 Antenna Relay
onFT-118
P/O SCR-283 Aircraft Radio
BC-409
Keying Unit
304TL and 14 tubes
P/O SCR-268
BC-410*
Radio Compass,500-1500 KC, 12 tube
CD-311*, DM-30,FT-145*, MO-4,5
P/O SCR-282
BC-411
DF Phase Inverter ControlBox
U/W BC-1147, MC-412
P/OSCR-291
BC-412*
Oscilloscope
5BP4 and 11 tubes
U/W CD-819, RC-68
P/O SCR-268
BC-413*
Radio Compass,
12 tube
CD-365*, DM-20*, FT-213, MO-4*
P/O SCR-273
BC-414
CBx
P/OSCR-273
BC-415
....
BC-416
Frequency Control Unit
BC-417
CBx
SW-142
P/OSCR-237
BC-418*
Antenna Relay
FT-440
P/ORC-64*
(* = Z-version for 12 VDC)
BC-419
Test Unit
BC-420*
Transmitter
DM-31*
P/ORC-48
BC-421
Antenna Reel Control Box
U/W RC-249, P/O ARA-4
BC-422
Control Box
P/O RC-53 Tank Interphone (radio op.)
TM11-700
1942
BC-423*
Modulator, 205 MC
5 tubes
S/T BC-927
U/W SCR-268
11-1106, 2636
BC-424*
Modulator, 205 MC. 5tubes.
P/O SCR-270, 271
BC-425
....
BC-426
Loop Director
BC-427
Radio Compass Unit
BC-428
Control Box
P/O SCR-279
BC-*-429
Receiver
.2-.4 + 2.5-7.7 MC.
4-39/44, 37, 38
FT-99
P/O SCR-283
BC-*-430
Xmitter, 2.5-7.7 MC
2-10, 2-45
FT-100
P/O SCR-283
TM 11-200
1942
BC-431
Radio Compass Rcvr, 12tubes
BC-432, FT-213, LP-19*, MO-4
P/O SCR-280
BC-432*
Control Box for BC-431
P/O SCR-280
BC-433*
Radio Compass,200-1750 KC, 13-17 tubes
U/W FT-213,MO-4B,5C,25
P/OSCR-269*
BC-434*
CBx
U/WBC-433, FT-224, SW-182 Relay
P/OSCR-269*
BC-435
Modulator
2250-TL and 8 304-TL
P/O SCR-268, 516Radars
BC-436*
Range Unit
3 tubes
U/W I-108,178, RC-68 calib eqpt
P/OSCR-268
BC-437
Converter
P/O SCR-268 Radar
BC-438
Frequency Meter, 190-215 MC 5tube
FU-26
P/O SCR-268,516,545
11-1106
BC-439
Frequency Meter, 100-120 MC,115 VAC
5 tubes
P/O SCR-270, 271
BC-440
CBx
P/O SCR-276
BC-441*
Marine Radio,1700-2750 KC 4-xtals 25 W
P/OSCR-281
TM11-244
1945
BC-442*
Antenna Relay
on FT-229
P/OSCR-274N
TO 08-5-57
1943
BC-442-AM
Antenna Relay without 50mmf HV capacitor
BC-443*
Radio Compass
12 tubes
DM-30
P/O SCR-263
BC-444
Control Box
P/O SCR-263
BC-445
Transmitter
used RM-45 for remote control
TM 11-811
1945
BC-446*
A-N Range Xmitter,200-400 KC, 100 W
17 tubes
TM 11-4006
BC-447*
Transmitter, 2-13.4MC, CW, 300 W
IS-166,167, RM-17-*
11-827
1944
BC-448
Tank Intercom Jack Box(driver and gunner)
P/O RC-53
TM 11-700
BC-449
CBx
P/ORC-53 Tank Interphone
(commander)
TM 11-700
BC-450*
CBx for 3receivers
on FT-222
P/OSCR-274
TO 08-5-57
BC-451*
CBx for up to 4transmitters
on FT-228
P/OSCR-274
BC-452*
Transmitter, 1.5-7 MC,50 W AM, 300 W CW 2 Chn
U/W RM-22
P/O RC-52
BC-453*
(R-23) Receiver, 190-550KC
6 tubes
P/O SCR-274
BC-454*
(R-26)
Receiver, 3-6 MC
"
P/OSCR-274
BC-455*
(R-27)
Receiver, 6-9 MC
"
P/OSCR-274
BC-456*
Modulator, 3 tubes,DM-33, FT-225
P/O SCR-274, IE-65,RC-55
08-5-57
BC-457*
(T-20)
Transmitter, 4-5.3 MC
4 tubes
FT-226,227
P/O SCR-274
BC-458*
(T-21)
Transmitter, 5.3-7 MC
"
"
P/O SCR-274
BC-459*
(T-22)Transmitter, 7.9.1MC
"
"
P/O SCR-274
BC-460*
Transmitter, 2-18 MC,250/200 W
36 tubes
Collins
P/O RM-20
11-812
BC-461
Antenna Reel RL-42 CBx
SW-154
U/W SCR-274, ARA-4
AN 08-10-3,82
1942
BC-462
CBx
U/W BC-463 Target Control Transmitter
P/O RC-56
BC-463*
Target Xmtr(T-53/ARW-8), 67-74 MC, 20 W, 5 AF channels, 16 tubes
AN-129, CD-869*, FT-442
P/O RC-56, ARW-8, TRW-1
BC-464*
Target Rcvr, 68-73MC
(5-1S4, 2-3G4)FT-441, PU-17
P/O RC-57, VRW-1
BC-465
Antenna Reel Control Box
BC-466*
Obstruction Light ControlBox
U/W CD-449, MP-42
P/O SCR-277
BC-467*
Nav-Aid Transmitter,200-400 KC, 1 KW, 9 tubes
P/OSCR-277
BC-468*
Goniometer AntennaCoupler
U/W BC-467,469, I-241
P/O SCR-277A
BC-469*
Antenna Tuning Unit
U/W BC-468, AN-33,34, I-241
P/O SCR-277
BC-470*
DF Rcvr and Loop..2-18 MC
PE-91*, SW-130
P/O SCR-206*
11-240
BC-471
Transmitter
BC-472
Modulator
BC-473*
CBx
for one receiver,
on FT-235
P/O SCR-274
BC-474
Radio Set, 2.3-6.5 MC, 7tubes (GN-44)
P/O SCR-288
11-250, 4006
BC-475
Portable Transmitter
U/W BB-208/AMT
BC-476
Recorder
BC-477
Receiver
BC-478
Receiver Control
BC-479
Meteorograph Unit
BC-480
"
"
"
BC-481
BC Receiver, standard 6 Vauto set "May be used with Halstead System."
BC-482
Receiver
BC-483
Receiver
BC-484
Transmitter Control
BC-485
Receiver
BC-486
Receiver Control
BC-487
Transmitter
BC-488
Transmitter Control
BC-489
Receiver
BC-490
Transmitter
BC-491
Target Controller
6J5, 80
U/W BC-617
P/O AN/ARW-1, RC-64 RCUnits
BC-492
Receiver
BC-493
Transmitter
807and 8 tubes
P/O RC-65
Target Controller
BC-494*
CBx
"
"
"
"
BC-495*
Test Unit for BC-464 TargetControl Unit
P/O RC-56,57
BC-496
Control Box (2receivers)
on FT-240 mount
P/O SCR-274
BC-497
Range Unit
4 tubes
P/OSCR-516 Radar (R/F SCR-268)
BC-498
Transmitter
BC-499*
Receiver, 20-28 MC,FM
11 tubes
BK-26
P/OSCR-293, 294
BC-500*
Radio Set, 20-28 MC, 25 W,FM, 18 tubes
Ry BK-26
P/O SCR-293,294
BC-511
Radio Set
U/W A-82 Dummy Ant, FT-252 Test Stand
P/O IE-15,17
BC-576*
Receiver
TM11-4026
1945
BC-583
Portable Radio, 2.2-4.6 MC,AM
(What happened to all the other BC-500numbers?)
BC-600
....
BC-601
Radio Set
BC-602*
CBx
P/OSCR-522 VHF Aircraft R-T
BC-603*
Receiver, 20-28 MC,FM
10 tube
FT-257,346
P/OSCR-508,528,538
BC-604*
Xmtr 20-28 MC, FM, 30W
8 tubes
P/O SCR 508,528,538
TM 11-4034
BC-605*
InterphoneAmplifier
on FT-257/468
P/O SCR-508,528,538
BC-606*
Interphone CBx
P/O RC-53, SCR-508,528,538
TM 11-700
BC-607
Remote Control Indicator
BC-608*
"Pseudo-IFF"British Transmitter-Keyer
C/O: BC-615,BK-31 Relay Units
U/W SCR-274N Xmtrs
P/O RC-96*
TM 11-1000
BC-609
Keyer
304TL and 10 tubes
P/O SCR-516 Radar
BC-610*
Xmitter, 2-18 MC,400/300 W, 16 tubes
C-387*-390,447-455Coils
P/OSCR-299,399,499
TM 11-813, 826, 4057
BC-611*
Walkie-Talkie, 3.5-6 MC, 5tubes.
BA-37,38, C-357-374 Coils,CS-136,
FT-504, HS-30, IE-75, SC-81 (test eqp IE-17:FT-252, CS-81*, I-135)
P/OSCR-536,538
TM 11-235,4019
BC-612
Modified BC-412 5"oscilloscope
12 tubes
P/O SCR-516*
BC-613
Antenna Reel Control Box
BC-614*
Speech Amplifier forBC-610, 7 tubes
P/OSCR-299/399/499
TM 11-281
BC-615
Relay Box
BK-31* Relay U/W BC-608
P/O RC-96 ID Keyer
08-10-68
1942
BC-616
Relay Box
BK-29,30C Rys, RS-260
P/O RC-96 Keyer
TO08-10-69
1942
BC-617*
RC Rcvr-Selector,30-40 MC, FM. 3 MC IF
U/W BC-622,CD-866, FT-464,465
5-channel:1620,2770,3180,4450,6250 cps
17tubes
P/O RC-64*, VRW-1
BC-618
Radar Receiver, 200 MC
15 tubes
P/O SCR-516
BC-619*
Antenna Tuner,1700-2750 KC
U/W BC-441
P/O SCR-281
TM 11-244
BC-620*
FM Radio, 20-28 MC 2 WFM, 13 tubes. BA-41, IS-171, ME-73, PE-97/120
TM11-605,615
P/OSCR-509/510/610
BC-621
Transmitter
16 100TS tubes
P/O SCR-516 Radar
BC-622*
Target Receiver Relay Unit,U/W BC-617, CD-866
P/O RC-64*, ARW-1
BC-623
Modulator
5 tubes
P/OSCR-516 Radar
BC-624*
Receiver, 100-156 MC10 tubes
PE-94*
U/W BC-625
P/O SCR-522,542
alsoP/O SCR-574,575,624, AN/CRC-2
BC-624-AMB
A special Purposevariety, classified... (SECRET)
BC-625*
Transmitter, 100-156MC, 15 W
8 tubes
PE-100*, SO-151
U/W BC-624
P/Oabove SCR units and CRC-2
BC-625-AM
Transmitter
P/O AN/CRC-2
BC-626
CBx
BC-627
CBx
BC-628
Transmitter
BC-629*
JkBx (pilot)
U/WJB-29
P/O SCR-522,542
08-5-76
1943
BC-630*
JkBx (crew interphone)
P/O SCR-522
08-5-76
1943
BC-631*
JkBx (2nd crewposition)
P/O SCR-522,542
08-5-76
1943
BC-632
Keying Unit
BC-633
Oscilloscope
BC-634
Oscilloscope
BC-635
Receiver
BC-636
Transmitter
P/OSCR-274
BC-637
Radar Range Unit
BC-638
Freq. Meter, 100-156 MC
7 tubes
U/W SCR-564,575
P/O RC-76,78,79,256
BC-639*
Receiver, 100-156 MC,10 tubes
U/W CD-1083,1084,1085, 1386,LS-3 Spkr,
MC-554,
PL-308,309,310, RA-42
P/O SCR-563,564,565,574,575,633,644,645,
P/O AN/CRC-2
BC-640*
Xmtr, 100-156 MC, 40W, 23 tubes
ME-41, PN-8-13*
P/OSCR-562,573,642,643
BC-641*
Public Address Amplifier, 2W
U/W PA-4-* PA Set
BC-642
Transmitter, 2.5-20 MC,AM-CW, 3 KW
10-channel
U/W RA-44, RM-15
BC-643
Modulator
U/W BC-642
BC-644
Transformer andContactor
U/W BC-642
BC-645*
IFF Set, 435-500 MC(CG-43AAG)
WE-316 + 14 tubes
U/W BC-646, PE-101*
P/OSCR-515/ABA-1
AN 08-5-50/62
1942
BC-646*
Control Box
U/W BC-645 (CG-23AB)
on FT-256
P/O SCR-515*/ABA
1942
BC-647*
Aircraft IFF Unit
Receives from SCR-268/270 Radars, thenalternates
retransmission between 102-112and 175-225 MC
FT-247
P/O SCR-535
BC-648*
IFF Control
P/O SCR-535, 595
BC-649
Impact Switch Box, seeBC-706
08-5-50
11-42
BC-650*
Receiver
two each 1D8, 957 tubes
U/W IE-16
P/O SCR-535*
BC-651
Oscillator
BC-652
Receiver, 2-6 MC
11 tube
DM-40,41, FU-42
P/O SCR-506
11-630, 4008
BC-653
Transmitter, 2-4.5 MC 100W-CW, 50 W, AM. 7 tubes, inc. 1613, 807, 814
BC-658* CBx, DM-43, IS-182 RFAmmeter
P/O SCR-506
TM 11-4007
BC-654*
Field Set, 3.8-5.8 MC,25 W
13 tube
IS-149, PE-103,104
RS-266
Crosley
P/O SCR-284*
TM11-275
BC-655
D-F Alignment Transmitter,17.5-158 MC
958, 1S5 tubes
U/W AT-103
P/O RC-93, SCR-555, SCR-575
TM11-4050
BC-656
Receiver
BC-657
Transmitter
BC-658
Control Box (Radio-Intercom)SW-155
U/W BC-652, BC-653
P/O SCR-506
BC-658*
Control Box, modifiedfor VRC-3
BC-659*
Jeep Radio, 27-39 MC,2 W, 14 tubes
U/W ME-73, PE-117*,120*
P/OSCR-609,610, CRN-10
TM 11-615,4023
BC-660
Indicator
BC-661
Oscillator
BC-662
Radiosonde Oscilloscope
P/O SCR-258
BC-663*
Receiver
12 tubes
P/OSCR-533
Mk IV, Long-Range IFF Set
BC-664*
Transmitter
500 MC
two 15A tubes
P/O SCR-533
BC-665*
Oscilloscope
5BP4 CRT and 8 tubes
P/O SCR-533
BC-666*
Generator andKeyer
11 tubes
"
"
BC-667
Interphone Amp. 24 V,
S/T BC-367
DM-45*
P/O RC-53,99
11-700,702
BC-668
Modulator
BC-669*
Radio Set, 1650-4450KC, 45 W, 385 KC IF, 6-ch, 15 tubes
U/WRM-21
P/O SCR-543*
TM 11-625*,4058
BC-670*
Remote Control Box,for RA-38
P/O RC-68 U/W SCR-268
11-1053 1944
BC-671
Receiver Output Box
P/O Test Equip. RC-68,A for SCR-268
11-1053 1944
BC-672*
Polarized AC Outlet Box P/ORC-68 U/W SCR-268
11-1053 1944
BC-673*
V-127 Tube Tester
P/O RC-68 U/W SCR-268
11-1053 1944
BC-674
Range Unit
Radar
BC-675
Range Unit
Radar
BC-676
Receiver
BC-677
Radar Transmitter
S/T BC-407
P/OSCR-268A
TM 11-1060
1943
BC-678
Interphone Box
(Mic, Phone, VC and Sw)
P/ORC-53*
TM 11-700
BC-679
Keying Unit
S/T BC-409, plus extra cathode keyer
P/O SCR-268-A
BC-680
Receiver and OscilloscopeUnit
BC-681
Transmitter
pistol-grip shape...used for receivernoise-testing
BC-682
Oscilloscope
BC-683*
Receiver, 27-39 MC, FM2.65 MC IF, 10 tubes (S/T BC-603)
P/O SCR-608/628
TM 11-620
BC-684*
Xmtr, 27-39 MC, 30 WFM, 8 tubes, (BC-604 Series)
P/OSCR-608/628
TM 11-628,4037
BC-685*
Radio Relay Unit
8 tubes
(Bendix)
P/O SCR-574
Net Control System
BC-686*
RC and Line Amp, 3 25L6 tubes
U/WBC-639,640, RC-72,86,155,168,203,
RC-204
RM-18
P/O SCR-561,567,572,574,575, 642,644,645 Net Control
BC-687*
Relay Unit
4 25L6tubes
U/W BD-102*, SCR-575,642,645 DFSets
1944
BC-688*
Altimeter Rcvr, 515MC
10 tubes
CD-647
P/O SCR-518
BC-689*
Altimeter Xmitter, 515MC
12 tubes
CD-649
"
"
"
BC-690*
Indicator Control
2 6AC7tubes
CD-648
"
"
"
BC-691
Radar Training Device
14 tubes
P/O RC-111
BC-692
Interphone Amplifier
BC-693
Receiver
BC-694
Receiver
BC-695
VHF Receiver
A W.E. Co. prototype evolving into the BC-942
BC-696*
Transmitter, 3-4 MC,30 W, 4 tubes
P/O SCR-274
BC-697
Transmitter
BC-698
Transmitter
BC-699
Transmitter, 1.68-4.45
MC
P/O SCR-274N
BC-700
Radio Set, 170-196 MC
P/O SCR-521 Radar
1944
BC-701*
Receiver, 170-196 MC.30 MC IF, 11 tubes
FT-265
P/OSCR-521
BC-702*
Xmitter, 170-196 MC
6 tubes
CD-693,FT-266, IE-13
P/O SCR-521
BC-703*
Control Panel
FT-267, PL-172, SO-233
P/O SCR-521
BC-704
Range Indicator, 5BP1, 7tubes. BD-905, CD-540, FT-268, IE-13-A, M-273
P/O SCR-521, TRS-1
BC-705
BatterySw-Bx "H"
P/O SCR-515/ABA IFF Set
1942
BC-706*
Detonator ImpactSwitch
U/W SCR-515,595,695
TO 08-5-50,62
1942
BC-707
Jack Box
BC-708
Test Box for BC-406 Rcvr
U/W RC-68* Test Set
P/O SCR-268
11-1053
BC-709*
InterphoneAmplifier
3S4 tube
FT-273, SW-210
P/O RC-73
BC-710
CBx
BC-711
CBx
BC-712
Antenna Relay Unit
BC-713
SCR-269 RDF Test Set
VTVM, meters
5 tubes
(I-100* items)
BC-714
SCR-269 Loop Test
5 tubes
U/W CD-549,550,551,552, I-112
P/OBC-713
BC-715
SCR-269 LoopTest Set
U/W CD-549,550,551,552,I-100*
BC-716
Radar Receiver, 700 MC, 14tubes
P/OSCR-296
BC-717
Xmitter
6 tubes
P/OSCR-296
BC-718*
Oscilloscope
3AP1/4 and 6 tubes
P/OSCR-296
BC-719
Oscilloscope
5HP1 and 19 tubes
"
"
BC-720*
Modulator
8 tubes
"
"
BC-721*
Glider Radio, BC-721,3.5-6 MC
5 tubes
U/W BA-37,38, BC-722, FT-295,
MC-355/365
P/O SCR-585
BC-722*
CBx
(GalvinRadio)
U/W BC-721, FT-295
P/O SCR-585
BC-723
Range Unit
two 6SJ7
P/OSCR-296 Radar
BC-724
Power Drive
"
"
BC-725
Calibrator
U/WSCR-296 Radar
11-1048
1942
BC-726
Calibrators I-147, 156,168
3 tubes
U/W SCR-296 Radar
11-1128
1943
BC-727
Destructor StatusIndicator
2 red lamps
U/W RC-134,135
P/O SCR-515
BC-728*
Receiver, 2-6 MC,4-channel, 7 tubes
CD-618, FT-338
P/O SCR-593
TM 11-859, 4005
BC-729*
TN/339
Antenna Tuning Unit
U/WBC-610
P/O SCR-299/399
BC-730*
Audio Amplifier
5 tubes
(AM-864/T-4/FRC)
P/O BC-329
BC-731*
Control Box for PE-95,150 VAC Mtr, 8 fuse holders
P/OSCR-299/399
BC-732*
Control Box
U/W BC-733 Receiver
P/O RC-103 ILS
BC-733*
Localizer Receiver,108-110 MC, 6-Ch. 10 tubes
DM-53*,FT-293
U/WCRM-3
P/O RC-103 ILS
AN 08-10-104
1942
BC-734
Control Box
BC-735
Control Box
BC-736
Interference Reducer
U/W BC-403,404
P/O SCR-270,271
11-1125A
1942
BC-737
Microphone Amplifier
BC-738*
Radiosonde Transmitter, 72MC
P/O ML-141-B
BC-739*
Interphone CBx
U/WCords CD-1251,1252
P/O RC-99
TM 11-702
BC-740
S-Band Radar Rcvr-Xmitter, 15tubes
CD-635,SO-213
P/O SCR-520
BC-741*
Indicator
21 tubes, inc. 12 6AC7, 3EP1/1812P7 CRT
"
"
BC-742*
Indicator
3EP1/1812P7 CRT
CD-641,642,643
"
"
BC-743
Synchronizer
21 tubes
M-377 Scope Visor
"
"
BC-744
IFF Component
CD-630,637
U/W SCR-268,520
P/O RC-98 IFF
BC-745
"Guidon Radio", 2-6MC.
9 tube
CD-571, T-39
P/O SCR-511*
11-866
BC-746*
Tuning Unit
U/W BC-745 (various frequencies)
P/OSCR-511
BC-747*
P-Band Radar Xmitter
CD-595-599, PL-Q227, SO-207
P/O SCR-540*
BC-748*
Modulator
CD-593,595-599,601, PL-Q227, SO-207
"
"
BC-749
Receiver
CD-593,600,601
"
"
BC-750*
Radar Indicator
3EP1/1812P7 CRT w M-371 Visor,CD-594,599,600
PL-229,SO-209
P/O SCR-540*
BC-751
ILS Xmitter
4E27 Pentode
U/W BC-752
P/O RC-107,CRN-3, MRN-1
BC-752
Modulator and RF Bridge
U/W BC-751
P/ORC-107, CRN-3, MRN-1
BC-753
Off-Course Detector, 4 tubes,IS-77 Ammeter
P/O RC-107, CRN-3, MRN-1
BC-754
"
"
"
6 tubes and PS
P/O RC-107, CRN-3, MRN-1
BC-755
Field Intensity Meter
BC-756*
Xmitter CBx
U/W BC-925, CD-866
P/O RC-64,65*, ARW-18
BC-757
Control Unit
P/O RC-107,CRN-3, MRN-1
BC-758*
Keying Unit
15 tubes
U/W RA-60, CD-761
P/O SCR-270-DA
BC-759
CBx
P/O SCR-270
BC-760
Oscilloscope
P/O SCR-270
BC-761
Signal Generator
1-955 tube
P/OI-109, IE-55
BC-762
Oscilloscope
BC-763
Test Set
BC-764
Receiver, .5-39 MC
"Super Pro" like BC-1004
P/O SCR-244A
TM11-866
BC-765
Two-PB Destructor SwitchU/W SCR-595/695 IFF Set
(SW-190) P/ORC-135
BC-766
Oscilloscope
BC-767
Detonator Warning Unit (twored lamps)
P/O SCR-515,535,695 IFFSets
BC-768
IFF Receiver, 470 MC
U/W SCR-270
P/O RC-98,100
BC-769
IFF Xmitter, 470 MC
U/W SCR-271
P/ORC-98,100,101
BC-770
IFF Keying Unit
P/O RC-98,100
BC-771
Frequency Meter, 94, 98, 470MC
U/W BC-769, P/O RC-98,100,101
BC-772
Remote CBx
U/W SCR-268, P/ORC-98,
BC-773
CBx
U/W RC-100
BC-774
CBx
PL-249, SO-189
U/W RC-101, P/O SCR-271
BC-775
Oscilloscope
BC-776*
Oscilloscope
BC-777
Alarm Indicator
3 tubes, Bell, Lamps, IS-177
P/O RC-107, CRN-3
BC-778*
Xmitter, T-74 (GibsonGirl) 500 KC (later CRT-3 + 8364 KC)
P/OSCR-578
BC-779
Receiver, 100-400 KC and2.5-20 MC
U/W CH-104, MC-531 Xtal Kit,RA-94
(Super-Pro SP-200)
TM 11-866
BC-779A
Receiver, .54-31 MC
SP-110/210
U/W RA-74,84,94
TM 11-866
1943
BC-779B
Receiver, 1.2-40 MCHammarlund SP-110-
R-129/U
BC-780
Pulse Indicator
5 tubes
P/OSCR-270, 718
BC-781
Indicator, 1812P7 and 20tubes
P/O SCR-517 Radar
BC-782
Relay Box
BC-783
Amplifier
P/O RC-100* IFFSet
BC-784
Amplifier
BC-785*
Radar Transmitter, 109MC, two WL-530
CD-761
P/O SCR-270
TM 11-1570
BC-786
Oscilloscope
BC-787*
Receiver, 28-143 MC(Halicrafters S-27/S-36), 15 tubes,
onFT-377
P/OSCR-607
TM 11-867
BC-788*
Radar Altimeter,420-450 MC
14 tube U/W CD-800, I-231,MT-14
SCR-718
BC-789*
Control Box
U/W CD-682, JB-53*, PL-249, SO-189
P/O SCR-517*
BC-790
Radar Training Device
7 tubes
S/T BC-691
P/O RC-110
BC-791
Recorder, code, using inkedpaper tape
P/O EE-94,95,96
BC-792
"Suitcase Set" DFReceiver, .1-65 MC, 8 bands, 8 tubes
P/OSCR-504
TM 11-862, 4060
BC-793
Radar Synchronizer
BC-794*
Rcvr, 150-400 KC +2.5-20 MC
U/W MC-531 Xtal Kit,RA-94*
SCR-244
(Hammerlund 400)
TM 11-866, 4054
BC-795
Xmitter
BC-796
Keying Unit (has destructorunit)
BC-797*
Transmitter, 116-126MC, 50 W, 16 tubes
U/W CH-205, RC-254
P/OSCR-641
TM 11-650
BC-798*
Receiver, superhet
115 VAC
BC-799
Oscilloscope
BC-800*
"Rebecca"Beacon, 160-186 MC, 19 tubes
S/TGPX-2.
BD-122,142,
C-134/APN, CD-1061-1064,FT-386,416, MC-215, MX-196/APN, TR-32
U/W or P/OSCR-602,729, APN-2, RC-192*
TM11-1133
1943
BC-800A
Rebecca Trainer
18 tubes
P/O RC-192*
TM11-1133
1943
(what happened to theother BC-800s numbers?)
BC-900
....
BC-901
Xmitter, 200-400 KC, 16tubes
FT-381
P/O RC-139, T-65/CRN-11, GRN-1
BC-902*
Marker Beacon Xmtr, 75MC
12 tubes
P/O RC-115 and SCR-241
BC-903
Receiver, .55-30 MC (NC-100A)
10 tubes
P/O SCR-255 DF Set
TM 11-861
BC-904
DF Target Xmitter
P/OSCR-255 DF Set
TM 11-861
BC-905*
Range Calibrator
four 6AC7 tubes
P/O IE-13
BC-906*
Frequency Meter,145-235 MC (1S5)
CD-713, FT-717
P/O IE-13,46,48,50,
IE-56, RC-147, SCR-521
TO 08-10-107,TM 11-2623
BC-907
Antenna Tuning Unit,200-400 KC
U/W BC-901
P/O RC-139
BC-908*
Amplifier, FacsimileSet
CD-606
P/O RC-58
TM11-4025
BC-909
Control Box
P/O SCR-517
BC-910*
Oscilloscope
3EP1/1806P1 and 11 tubes
CD-612,613,615,617, CH-99
WE Co.
U/W SCR-520
P/O IE-30
BC-911
Switch Box
(Radar? It has English co-ax connectors)
BC-912
Keying Unit 7 tubes, inc. 2Eimac 304TH (in FM-53)
P/O SCR-582
BC-913
Antenna Switch
BC-914*
Test Unit for BC-622Relay Unit (P/O RC-64 Target Control Receiver)
BC-915*
Power Control forairfield runway obstacle light PS PE-141 6/115 V
P/O SCR-241,591, SCR-592,MRN-1, CRN-3
BC-916
RF Unit
BC-917
Oscilloscope
BC-918*
Fax Recorder
U/W CD-606, MC-308B, MO-28,38, RS-278,288,VB-3
P/ORC-58
TM 11-4027
BC-919
CBx
P/O RC-119
BC-920*
S-Band Radar Test Set
18 tubes
CD-612-617, CH-98
P/O IE-30-*
BC-921
Transfer Selector
BC-922
Modulator
8 tubes
in Rack FM-53
P/OSCR-582
BC-923*
Receiver, 27-39 MC,FM, 4 Chn
U/W RA-125
DM-64A/12V;DM-66A/24V
P/OSCR-808/828
TM 11-4030
BC-924
Xmitter, 27-39 MC, FM4-chanel
DM-65A/12V, DM-47A/24V
TM 11-601
P/O SCR-808/828
TM 11-4030
BC-925*
Mod.-Xmitter, 30-40 MC, 25W, FM
U/W BC-494, PE-180
P/O RC-65
BC-925-Z
12 VDC BC-925
10 AF Channels
P/O RC-65-Z
BC-925-T3
Target Control Trainer
BC-926
RF Amplifier
3 tubes
in rack FM-53
P/O SCR-582Radar
BC-927
Antenna Relay
on FT-341
U/W SCR-269* ILS version
BC-928
Keying Unit
1366 and 4098 pps
U/W BC-677,1103
P/O SCR-268*
BC-929*
Radar Oscilloscope, 3"CRT: CD-799, FT-409
U/W RC-170,BC-949
R/B ID-169B/
P/OSCR-729, APB-1, APN-2Y
BC-930
Test Set
BC-931
B-Scope
5FP7 CRT
P/OSCR-517
BC-932
Indicator Amplifier forBC-931
4 tubes
P/O SCR-517
BC-933
Xmitter
BC-934
Training Unit
BC-935
Relay Box
P/O RC-65, ARW-1 TargetControl
BC-936*
F-S Indicator
1-957 tube
U/W BC-949
P/O IE-36, IE-56-A IFFTest Sets
BC-937*
Voltage Regulator
U/W CD-739, PE-118A, RM-37*
P/O SCR-517*,720*
BC-938
A-Scope
U/W BC-950, CD-704
P/O IE-65, RC-55
BC-938
CBx
U/W CD-704, HF-VHF SCR-274N radios, such asR-19 (SIG 5-1)
BC-939*
Antenna Tuner 2-18 MC 400W
U/W BC-610, MP-47
P/O SCR-288,299,399,499,368
Also U/W T-368/URT Xmitter
TM 11-809
BC-940
Control Unit
BC-941
Range Unit
11 tubes
P/O SCR-547
"Mickey Mouse" twin-dish radar
BC-942
Receiver, 100-156 MC, 4chns
S/TR-28/ARC-5
CD-694,706, I-104
U/WSCR-274N/ARC-5
BC-943
CBx
BC-944*
CBx
CD-697,698
U/WSCR-274
P/O RC-54,55 Test Sets
BC-945
Indicator Box
BC-946*
Receiver, 520-1500KC
DM-32*
P/OSCR-274
1943
BC-947
Radar Xmitter, 10 cm, 1 KW
7 tubes
WE Co.
P/O SCR-547
BC-948
Receiver
BC-949
Range Calibrator 2 tubes,CD-799
U/W BC-929,936
P/O IE-55,56
TO33A1-10-4-2
BC-950*
Xmitter, 100-156 MC, 5tubes
CD-704
S/T T-23/ARC-5
P/O SCR-274N
BC-951
Filter Unit
2 FL-12, 1 FL-14
BC-952
Radar Receiver, 22 tubes(2JB-51)
FM-52, RC-62
P/O SCR-582
BC-953
Training Unit
"
"
BC-954
Oscilloscope
6E5 and 1813P7 CRT
FM-52
U/WFM-52
P/O SCR-582
BC-955
Power Control Box
U/W CD-675*,692
P/OSCR-517
BC-956
Oscilloscope
1802P1 CRT and 12 tubes
P/O SCR-582 Radar
BC-957
Elevation Indicator, 5HP4 and46 tubes
P/O SCR-547
BC-958*
Keying Unit
BC-965, RA-67
U/W SCR-595,695, RC-255,ABK-* IFF Sets
Navy Type CHZ-23ABH (HazeltineMfg. Co.)
BC-959
Antenna Tuning Unit
BC-960
CBx
BC-961
Antenna Switching Unit
one WL532
P/OSCR-521 Radar
BC-962
SwBx
BC-963
Receiver
BC-964
Xmitter
P/O SCR-274N ?
BC-965*
Code Selector Box
BC-958
U/WSCR-595,695*, RC-255, ABK-* IFF Sets
NavyType CHZ-23ABH (Hazeltine)
BC-966*
IFF Receiver, 160-211MC
13 tubes
CD-695
P/O SCR-695
3 in B-25
BC-967
Receiver, 18-156 MC,AM-FM
RA-61
P/O SCR-613
BC-968*
Radar Trainer U/WBC-412. TC-1, TS-33
U/WSCR-268,270,271
11-1062
44
BC-969*
Receiver, 15-6000 KC(S/T RAK) CD-872, RA-61
P/O SCR-614
11-873,4013
BC-970
Xmitter
BC-971
Receiver
BC-972
CBx
BC-973*
DF Receiver, 1-3 MC, 11tubes
MC-323, PE-133
P/O SCR-503*
TM 11-246, 4028
BC-974
Receiver, 2-20 MC, AM-FM,8-Bands
15 tubes
CS-149
BC-975
Indicator Box
BC-976*
Aircraft DF Rcvr, 2-20MC
13 tubes
PE-151 Vib PS
P/OSCR-551
BC-977
Aircraft ECM Rcvr, 38-3300MC, 7 tubes
AN-97, CD-677, FT-347,TU-57,
TU-58
P/OSCR-587*
BC-978
DF Test Xmitter, 2-20 MC
2 1A5tubes
P/O SCR-551
TM 11-4004
BC-979
Antenna Control Unit
BC-980
Antenna Receiver
Radar
BC-981*
Radar Rcvr, 200 MC 18tubes
U/W BC-1340, FM-51
P/O SCR-527,627
BC-982
Radar Xmtr, 200 MC 4GL434.
CD-1046, MC-327, RA-67
P/O SCR-527,627
BC-983
Modulator
S/T BC-423
CD
P/O SCR-527
BC-984
Modulator
16 584 and 9 784 tubes
P/O SCR-584, 784 Radars
BC-985
Keyer
7 tubes (4 807)
U/W MC-596,606, RA-67
P/O SCR-527, 627
BC-986*
A-Scope 10GP7 CRT
U/W FM-51, PE-138
P/O SCR-270,271,527,627 Radars
BC-987*
PPI-Scope 12DP7 + 7tubes
U/W FM-51, PE-139
P/O SCR-527,627
BC-988*
Calibrator, 18.62KC
12 tubes
U/W FM-51, I-240
P/O SCR-527*,627
BC-989
RF Oscillator 15 tubes
Rack FM-51
P/OSCR-527, 627
BC-990
Relay Unit
BC-991*
CRT Indicator, 10tubes
U/W BC-976, PE-151
P/O SCR-551,555
11-4003
BC-992*
Indicator, 7BPN + 8tubes, M-376 Visor, CD-709,718,737-739, RA-77*,
RM-37*, SO-231
P/OSCR-517*
BC-992-T*
Training Version
same accessories
P/O SCR-517-T*
BC-993
Synchronizer, 3EP1 and 16tubes,
CD-709, FT-353
P/O SCR-517*
BC-993-T*
Training Version
same accessories
P/O SCR-517-T*
BC-994*
Control Box
U/W CD-678,697,698, FT-354, PL-P281, RA-77*,RM-37, T-3,
SO-261
P/O SCR-517
BC-995
Servo Amplifier
6N7, 2-6L6tubes
P/O SCR-517
BC-996
Interphone Amp
BC-997
Receiver
BC-998
RC Receiver and Selector
BC-999
Modulator and Xmitter
BC-1000*
Field Radio, 40-48 MC, 2W, FM, 18 tube.
U/W BA-30,42,70,FT-338
P/O SCR-300,VRC-3
TM 11-637, 4024
BC-1001*
Receiver
BC-1002
Analyzer
BC-1003*
DF Receiver, .1-1.0 MC 13tubes
LP-33, MC-323
P/O SCR-503
TM 11-246
BC-1004*
Super Pro Receiver, .54-20MC, 16 tubes,
U/W MC-531 Xtal Kit,RA-84,
P/OSCR-244/292
TM 11-1866, 4054
BC-1005*
DF Rcvr, 18-65 MC, 4.2 MCIF, 15 tubes,
AN-105-A, CD-859,1028,
PE-155
P/O SCR-555*
TM11-251,4047
BC-1006*
DF Rcvr, 65-156 MC, 8.25MC IF
AN-106-A, CD-859,1029, PE-155
P/OSCR-556*
TM 11-255
BC-1007*
Modulator, three 705A
U/W CD-1094, MC-494
P/OSCR-717
ASW Radar
BC-1008
Control Unit
BC-1009
Control Unit
BC-1010
Receiver
BC-1011*
Ant. Control
U/W MC-298
P/OSCR-270, 271
1943
BC-1012*
Ant. Control
S-196
"
"
"
1943
BC-1013
Control Unit
BC-1014
Xmitter
BC-1015
Radar Range Indicator
BC-1016
Code Recorder, inked paper type
U/W BC-1164, CD-932
TM 11-441
BC-1017
Jamming Xmtr, 450-710 MC, 8 W, 10 tubes
(T-26/APT-2)
P/O RC-156,183
BC-1018*
Receiver
CD-734, PL-Q261, SO-241
U/W BC-1028*
P/O SCR-618*
BC-1019
Interphone Amplifier
P/O RC-273
BC-1020
Radio Set
BC-1021
Oscilloscope
BC-1022
Control Unit
P/O RC-209, U/WSCR-271
BC-1023
Marker Beacon Rcvr, 75 MC, 12 V, 4 tubes
P/O RC-193*
TO 08-10-150
BC-1024
Frequency Reducer(Converter?)
BC-1025
Radio Set
BC-1026
Relay Box
BC-1027
Oscilloscope
BC-1028*
Xmitter
CD-733,734, PL-Q262, SO-242
U/W BC-1018, I-188
P/O SCR-618*
BC-1029
Radio Set
BC-1030
Xmitter
BC-1031*
Panoramic Adaptor
U/W SCR-206,503
P/O TC-8 DF Set
TM 11-446,4048
BC-1032*
Pan. Adpt. for 5.25 MC IFradios
U/WSCR-607
TM 11-446, 4049
BC-1033*
Marker Beacon Rcvr, 75MC
3 tubes 24 V
P/O RC-193A
08-10-157
4-43
BC-1034
Control Unit
BC-1035*
Range and AzimuthIndicator
34 tubes, 2 5CP1 CRTs
P/O SCR-545
BC-1036*
Control Unit
U/W SCR-271-D
P/O RC-209
BC-1037
Transmitter, 5 tubes
U/W BC-1039
P/O SCR-545
BC-1038
Receiver
BC-1039
Xmitter
5 tubes
P/O SCR-545
BC-1040
Radar Rceiver-Xmitter, 10 cm
14 tubes
P/O SCR-520
BC-1041
Radar Indicator, 5FP7 and 22 tubes
"
"
BC-1042
Modulator
3 705 tubes
P/OSCR-720 Radar
BC-1043
Synchronizer
21 tubes
P/OSCR-520 Radar
BC-1044
Control Box
"
"
"
BC-1045
Synchronizer
7 tubes
"
"
"
BC-1046
Relay Box
BC-1047*
Range Unit Control
(Philco)
U/WBC-1053, P/O SCR-545*
BC-1048
CRT Deflection Unit
U/W SCR-271-D
P/O RC-209-A
BC-1049*
Elevation Control Unit
P/O SCR-545
BC-1050
Radio Set
15 tubes
P/OSCR-517
BC-1051
Frequency Control Unit
P/O SCR-545
BC-1052*
Range Unit
P/O SCR-545
BC-1052
Multi-meter Test Set (according toSIG-5)
U/W SCR-299,399,499
BC-1053
FC Range Computer, 34 tubes
U/W BC-1047,1102
P/O SCR-545 Radar
BC-1054
Control Box
"
"
BC-1055*
Radar Rcvr
30 MC IF
40 tubes
"
"
BC-1056*
Radar Rcvr
30 MC IF
14 tubes
U/W AN-101-A Antenna,
MC-581,607 S to X-Band Conv. Kit
P/O SCR-584,784
BC-1057*
S-Band Receiver
38 tubes
500 lbs
P/O SCR-545
BC-1058*
PPI Driver
5-6L6,13 6SN7 tubes
P/O SCR-584*, 784
BC-1059*
Azimuth Control Unit
70 tubes
P/OSCR-545
BC-1060*
Oscilloscope, 3GP1 and 13tubes
Dumont P/O RC-283
TM 11-2526
1944
BC-1061
Control Unit
BC-1062*
Range Computer 14tubes
U/W BC-BC-1047
P/O SCR-545,584,784
BC-1063*
Remote Control Unit
U/W BC-1055 Rcvr
P/O SCR-545
BC-1064*
Radar Beacon Xmitter,170-200 MC
24 tubes
CD-721,722,724, RA-81
U/W BC-1098 Coder
P/O RC-201, SCR-621,640,717,CPN-1
1944
BC-1065
Control Box
P/O SCR-545
BC-1066*
Receiver, 400-450 MC, 3tubes
P/O IE-46*, IE-56 Test Sets
TO 08-5-33
BC-1067*
Azimuth Control
P/O RC-145, SCR-545
BC-1068*
IFF Rcvr, 150-210 MC
FT-353
U/W SCR-268,271
P/O RC-148
TM 11-1117
BC-1069
Servo Amp,
10 tubes
P/OSCR-545
BC-1070*
Radar Trainer
U/W BC-1233, RC-148, SCR-268,270,271,UPS-T2
11-1058
BC-1071
Servo Amp, 31 tubes
P/O SCR-545/584/784
BC-1072
IFF Xmitter, 155-185 MC
FT-348
U/W SCR-268-A
P/O RC-148
BC-1073*
IFF-Radar Control incF-Mtr, 150-210 MC, U/W BC-1068; P/O RC-148,316
U/W SCR-268, 516
P/O RC-148,150,151
BC-1074*
PS and Video Amplifier 30MC IF, 4 tubes
RA-71
P/O SCR-584, 784
BC-1075*
Altitude Data Unit for M4and M7 Gun Directors
U/W BC-1094, RA-70
P/O SCR-584, 784 Radar Sets
BC-1076*
Antenna Position Indicator
P/O SCR-584, 784
BC-1077*
S-Band Sig Gen, 18tubes
S/T BC-1277
CD-956, CH-147
P/O IE-57
BC-1078*
30 MC IFPre-amplifier
two 6AC7
P/OSCR-584, 784
BC-1079
Oscillograph
BC-1080*
Radar Xmtr Driver
8 tubes
U/WBC-1373
P/O SCR-584, 784, MSQ-1
BC-1081*
Radar Xmtr, 212 MC,
U/W AN-102-A, JB-82, TR-32
P/O SCR-602*
BC-1081-T6 Radar Trainer Version, 6 tubes
P/O SCR-602-T6
BC-1082*
Receiver, 200 MC, 12tubes
U/W CD-976, JB-82
P/O SCR-602*
BC-1082-T6 Radar Trainer version
P/O SCR-602-T6
BC-1083*
9" scope, 9MP7 + 7tubes
CD-963-967, JB-82, PE-172
P/O SCR-602*
BC-1083-T6
TrainingOscilloscope
same tubes
P/O SCR-602-T6
BC-1084*
Indicator, 5GP7 + 7tubes
U/W CD-963-965,1063, JB-82(RC-192*)
also BC-1084-T6A Trainer
P/O SCR-602*
BC-1085*
Manual Antenna PositionControl
U/W MC-643,644
P/O SCR-584*,784
BC-1086*
Automatic TrackingUnit
5 tubes
P/O SCR-584,784
BC-1087*
Oscilloscope
3BP1 + 10 tubes
CH-157
P/O IE-57, AN/APM-7 (CW-60AAY)
BC-1088*
Range Ind. two 3DP1
U/W BC-1399, MC-578,581
P/O SCR-584, 784, MPG-2
BC-1089
Indicator
P/ORC-173 U/W
"
"
"
BC-1090*
Azimuth-ElevationTracker
16 tubes
P/O SCR-584, 784, MSQ-2
BC-1091*
S-Band Xmitter
7 tubes
CD-1094
P/O SCR-717,720
BC-1091-AM
"Tracer Box"(fixed T-R Box)
U/W BC-1091 RF Unit
BC-1092*
PPI Display, 7BP7
U/W BC-1370
P/OSCR-584,784
BC-1093
Indicator
1812P7 CRT and 6H6
P/OSCR-717 ASW
BC-1094*
Altitude Computer
15 tubes
P/OSCR-584,784
BC-1095
Synchronizer
27 tubes
FT-353
P/O SCR-717 Radar
BC-1096*
Oscillator, 2680-3300MC
7 tubes
P/O SCR-584,784
BC-1097
Control Unit
P/O SCR-717
BC-1098*
Coder Unit, 2AP1 and 16tubes,
CD-770, RA-81
P/ORC-201,232, SCR-621,640,717, CPN-1
BC-1098-T2
Radar Trainer
P/O SCR-621-T2,3 SCR-640-T1
BC-1099
Trainer Set
BC-1100*
Xmitter, 1.5-10 MC, 4-ch75/125 W
Xtal control
P/O RC-263
BC-1101
Indicator
like BC-1041
P/OSCR-517 Radar
10-1942
BC-1102*
Range Converter
31 tubes
S/T BC-1053
U/W SCR-545
P/O BC-105
BC-1103
HV Control
U/W BC-677,928
P/O SCR-268 Radar
BC-1104
Control Unit
P/O SCR-527
BC-1105
Range Calibrator
8 tubes
P/OSCR-588, SCR-636 Radars
BC-1106
Radar Receiver
P/OSCR-
BC-1107
Radar Computer
BC-1108
Control Box
BC-1109
Test Oscillator
BC-1110
Antenna Relay
BC-1111
Height Indicator
12HP7 + 9 tubes
in CS-108
P/O SCR-588, 636
BC-1112
Xmtr Monitor
1805/P1 CRT and 2X
in CS-118
P/O SCR-588
BC-1113
Control Unit
11 tubes
P/O SCR-597,636*
BC-1114
....
BC-1115
Sonobuoy Receiver
P/O RC-222
later ARR-3*
BC-1116
Xmitter
BC-1117
Xmitter
BC-1118
Receiver
BC-1119
Control Unit
10 tubes, inc. 2 FG105
P/O SCR-597 Hi-Power Xmitter
BC-1120
Antenna Coupling Unit
U/W A-88-B
P/O SCR-588 Long-Wave Radar
BC-1121
Receiver, 200-220 MC/31 MCIF, 9 tubes in
CS-108
P/OSCR-588, 636
BC-1122
Amplifier
"
"
"
BC-1123
Amplifier
"
"
"
BC-1124
Oscillator
"
"
"
BC-1125
Oscillator
(BC-1125-T2 Trainer)
"
"
"
BC-1126
RF Head Unit
"
"
"
BC-1127
Transmitter
"
"
"
BC-1128
Control Box
"
"
"
BC-1129
Modulator, 10 tubes (5807)
"
"
"
BC-1130
Crystal IF Mixer, U/W TR Box
P/O SCR-584, 784
BC-1131
Modulator
"
"
"
BC-1132
T-R Box
721A tube
"
"
"
BC-1133
Xmitter
"
"
"
BC-1134
Antenna Switch
8 tubes
RA-86
U/W Ant. A-88-B
P/O SCR-588,597
BC-1135
Azimuth PPI Display, 12DP7 andtubes
CS-108
P/O SCR-597,636
BC-1136*
Radio, 3.8-6.0 MC, 7/20 W,AM/CW
C/O: AN-123,124, CD-774,775,1072,
CD-1073,1086, GN-53,57, M-404, PE-156 Vib-PS
P/O SCR-694*
BC-1137*
Receiver, 3.8-6 MC
7 tubes
12 V Vib-PS
BC-1138*
Grid Control Unit
P/O SCR-588
BC-1139
Receiver Antenna Control
(one 6V6)
U/W CS-108
P/O SCR-588,597,636
BC-1140*
Control Box
P/O SCR-625 Mine Detector
TM11-1122
1943
BC-1141*
AF Amplifier
5 tubes
"
"
"
"
"
"
"
BC-1142*
Radar Modulator
17 tubes
P/OSCR-720
BC-1143
Radio Compass Unit
BC-1144
Control Box
BC-1145
Control Unit(C-3/APN-2)
U/W BC-800, FT-406
P/O SCR-729, APN-12,T1
BC-1146
Antenna Coupling Unit
U/W BC-1338, CD-1351, MC-551,552
BC-1147*
DF Receiver, 1.5-30 MC, 13tubes
U/W BC-1159, CD-830, FM-61,MC-412,
MC-413,472, PN-32,47, RM-43
P/O SCR-291,502
TM 11-256,4041
BC-1148*
Synchronizer, 28tubes
CD-1109, FT-333
P/OSCR-717,720
BC-1149*
Target Xmitter 1.5-32 MC,4-Band
P/O 291,292,502
TM11-849,4040
3B7 and 1R5 tubes, oneBA-35 and 3 BA-53 Batts
BC-1150*
Antenna Control Unit, 15tubes
on FT-415
P/O SCR-717,720
BC-1151*
Operator's Indicator, 25FP7, 2 6H6
CD-1109, FT-421
P/O SCR-717,720
BC-1152
Pilot's Indicator
3HP7 CRT and 6H6
CD-1109,1124
P/OSCR-720
BC-1153*
Range-Azimuth PPI (2 5FP7)CD-1094,1095,1097, FT-423
P/O SCR-717*
BC-1154
Modulator
BC-1155*
Synchronizer, 24 tubes
CD-1094,1157, FT-425, MC-595
P/O SCR-717*
BC-1156*
AZON Glide Bomb ControlBox
P/O RC-186
BC-1157*
Antenna CBx
U/WBC-1285, CD-1107, FT-417, MC-494
P/OSCR-717*
BC-1158*
Mod-Xmtr, 53-95 MC, 50 W,11 tubes
PE-186, TU-69,70/
P/O ARW-9and RC-186 Bomb Control System
BC-1159*
DF Bearing Indicator
5CP1/5NP1
U/W BC-1147, FM-61*, MC-412,551,
PN-31, RM-43,44
FTR Co.
P/O SCR-291*,502
TM 11-243,4063
BC-1160
IFF Xmitter, 157-187 MC, 1 KW PP
P/O RC-150,151
BC-1161
IFF Rcvr, 150-200 MC
14 tubes
U/W BC-1072
P/O RC-150,151
11-1117
BC-1162
Wavemeter and CBx
U/W BC-1161,SCR-270,271
P/O RC-150,151
BC-1163
Signal Monitor CBx
U/W CD-936,937
P/O RC-238,239 and RIC TC-9
BC-1164
Monitor Recorder CBx
U/W CD-907,929, RC-243,244
P/ORC-238; RIC TC-8,9
BC-1165
Signal Monitor CBx
U/W CD-936,937
P/O RC-238; RIC TC-8,TC-9
BC-1166
Calibrator
BC-1167*
Video Probe Amp. 6AC7
U/W BC-1087 Scope
P/O IE-57,AN/APM-37
1942
BC-1168
Sound-Ranging Radio Link
BC-1169*
Radar Beacon
18tubes
P/O RC-232
BC-1169-T2 Beacon Trainer
17 tubes
P/OSCR-640-T1
BC-1170
Interference Reducer
BC-1171*
Remote Control Box
R/B BC-1314
P/O SCR-624 (Ground-based SCR-522)
BC-1172
Receiver
BC-1173
Oscilloscope
BC-1174
Indicator
BC-1175*
Local Operation CBx
P/O SCR-522, 624
BC-1176*
Remote Control Box
U/W EE-8*
P/O SCR-522, 624
BC-1177
Trainer
BC-1178
Trainer
BC-1179
Receiver
BC-1180
Frequency Meter
BC-1181
LORAN Receiver
1.8-11.1 MC
S/T BC-1182
P/O SCR-722
BC-1182*
LORAN Receiver
9 tubes
U/WCD-979,980*
P/O SCR-722
BC-1183
Control Box
SingleControl for ARC-5 Receivers
P/O SCR-274
BC-1184*
LORAN Trainer, 5CP1 and 33tubes
U/W SCR-722, CD-979,980*
P/O IE-52, RC-252
BC-1185
Receiver and ChannelSelector
BC-1186*
Transmitter, 212 MC
10 tubes (2 NT-99 + 3 VU-111)
P/O SCR-636
BC-1187
Modulator
MC-614 Trigger Amplitude Kit
P/O SCR-636
BC-1188*
Antenna Switch, four VR78+ REL21
U/W CD-988,MC-436
P/O SCR-588,636*
BC-1189
Antenna Switch
U/W CD-876-879
P/O RC-173
BC-1190
Receiver
BC-1191
Transmitter
BC-1192
Transmitter
BC-1193*
CRT Control Unit
21 tubes
P/O BC-1225
U/W SCR-682 Radar
BC-1194
Modulator
U/W BD-1030, CD-942,944, FT-458, GA-9, RA-101
P/OSCR-682
TM 11-1561
BC-1195
Noise Discriminator
U/W BC-404
P/O SCR-270,271, etc.
BC-1196
Indicator
BC-1197
Computer
P/OSCR-519 Radar
BC-1198
Control Unit
U/W FT-431,438
"
"
"
BC-1199
Antenna Control
P/O SCR-519 and APQ-10 Radars
BC-1200
Capacitor Unit
BC-1201
Diode Probe Coupling Head
6H6 tube
P/OIE-45
BC-1202
Diode Probe Coupling Head
6H6 tube
P/OIE-45
BC-1203*
Amplifier-Modulator, 20tubes
U/W CD-1034
P/O IE-45
BC-1204
Training Adaptor for BC-463 Xmitter's BC-642control boxes
BC-1205
Steering Indicator
BC-1206*
Bacon Receiver, 200-420KC, 5/6 tubes
Setchell-Carlson ModelM-524
28 VDC
U/W C-140/MPN-1
TO 08-10-232
BC-1207
Destructor IndicatorBox
S/T BC-727 red-green lamps
P/O SCR-695
BC-1208
Oscillator
P/O SCR-636
BC-1209
Mobile Radio
2-46 MC, 40 W
U/W MP-15,62, PE-152,154
P/O SCR-583
BC-1210
Control Box
P/ORC-156
BC-1211*
Airborne TV Camera, 17tubes
FT-454
DM-56-B
P/O SCR-549/ATJ
BC-1212*
Airborne TV Xmitter,260-320 MC, 12 tubes
U/W AN-142-146Antennas,
CD-800,934,1200,1201, DM-56-B, FT-453, I-231
P/O SCR-549 (Navy ATK)
BC-1213*
TV Rcvr, 260-370 MC, 50 MCIF, 7CP1 + 6 tubes
U/W AN-163,164,165,
CD-800,1200,1205, FT-455
U/W IE-49
P/O SCR-550 (Navy AXR-1)
BC-1214
TV Monitor Unit, 7CP1 and 6 tubes
U/W I-232, IE-49,73
P/O SCR-550
BC-1215
Calibrator
BC-1216
Compensation Unit
BC-1217
Control Box
BC-1218
Modulator
BC-1219
RF Unit
BC-1220
Indicator Unit
BC-1221
Modulator
BC-1222
Antenna Drive
BC-1223*
Radar Receiver
19 tubes
P/OSCR-682
TM 11-1561
BC-1224*
Xmitter, 10 cm
721 and 2J32
P/O SCR-682*
BC-1225*
Range-Azimuth PPI
U/W BC-1193,1381, BD-123,124, CD-942,945,FT-458,
RA-100
P/OSCR-682
BC-1226
Radar Antenna ControlUnit
(A 2 ft cube; later became C-13/TPS-1)
BC-1227*
Oscilloscope
P/OSCR-627 Radar
BC-1228
Inverter PS Switch Box
U/W PE-218
P/O SCR-617
BC-1229
Adapter Box
U/W PE-118A
P/OSCR-717,720
08-10-173
BC-1230
Control Box
P/OSCR-274N
BC-1231
RF Oscillator
U/W BC-758
P/O SCR-270,271 Radars
BC-1232*
Radar Rcvr, 90-120 MC, 36MC IF
U/W BC-1270,1239
P/O SCR-270,271
BC-1233*
Oscilloscope (RC-158)simulates BC-403*
U/W TrainerBC-1070
11-1066
BC-1234
Oscilloscope
BC-1235
Signal Generator
BC-1236
Signal Generator
15-40, 95-115 and 195-230 MC
110 VAC input
BC-1237*
Radar Jammer, 85-150 MC,12 W
6 tubes
P/O RC-183
BC-1238
Control Box
P/ORC-183
BC-1239*
Indicator 12DP7,12GP7,RK60
U/W MC-575, PN-47 RC-271
P/O SCR-270,271
BC-1240
Xmitter
BC-1241*
RF Unit, 500 KW-Pk (two 721A)
U/W RA-108
P/O SCR-615-A
TM 11-1541
BC-1242*
Modulator
17 tubes
P/OSCR-615*, 717,720 Radars
BC-1243*
Local Oscillator
417Atube
P/O SCR-615-A
10 cm,GCI Radar
BC-1244*
A and R Indicators, 2 5CP7and 6SN7
P/O SCR-615-A, 615-T1
BC-1245*
PPI Display
7BP7 CRT
"
"
"
BC-1246*
Receiver
30 MC IF
25 tubes
"
"
"
BC-1247*
Pre-Amplifier
3 6AC7tubes
"
"
"
BC-1248*
PPI Control Unit
9 tubes
"
"
"
BC-1249*
Altitude Indicator
10 tubes
"
"
TM
11-1541
BC-1250*
Range Error Unit
15 tubes
P/OSCR-615-T1 Radar Trainer
BC-1251*
Synchronizer
23 tubes
P/OSCR-615-A,T1
BC-1252*
Console
P/O SCR-615-A
BC-1253
Radiosonde Xmtr, 397 MC
U/W BB-208/AMT
BC-1254
Test Set for SCR-269-FRadio Compass
U/W BC-713
P/O I-100-*
BC-1255*
Heterodyne Test Receiver,75-150 MC
958, 2-1S5 tubes
U/W RC-183
BC-1256
Antenna Control/Monitor
P/O SCR-636 Radar
BC-1257
Control Box
P/O RC-164
BC-1258*
Antenna Control Box
P/O SCR-717 Radar
BC-1259
Oscilloscope
BC-1260
Search Receiver
P/O APR-2
BC-1261
Control Unit
P/O RC-188
BC-1262*
Monitoring Unit
BC-1263
Antenna SwitchingUnit
U/W CD-987,988
P/O RC-188* IFF
BC-1264*
Control Cabinet
U/W BC-463 RC Xmtr, CD-987,988,1114
P/O RC-188*
BC-1265
Control Box
BC-1266*
Monitor, 5CP1 + 14tubes
CD-1105, RA-105
U/W SCR-545
P/O RC-145*
BC-1267*
MK-3 IFF Set, 157-187 MC,11 MC IF, 1.5 KWP, 21 tubes,
FM-79,FT-85,
MC-498, RA-105
U/W BC-1293 Indicator (5CP1)
P/ORC-127,145,182,184,188,207,215,246,282,350,351,AN/CPX-1
TM/TO#s
BC-1268*
Range Control Unit, 5CP7and 24 tubes
FM-80, RA-105
U/WSCR-584
P/O RC-182,184
BC-1269*
Monitor Receiver, 145-600MC, AM/FM, 15 MC IF 17/19 tubes (R-593/GRR)
U/W RA-61* PS, RC-281 ANT, CH-269,271,270,CD-272,273,927, FT-411,414
P/OSCR-616
TM 11-260
BC-1270
Noise Discriminator, 11 tubes
U/W BC-1232
P/O SCR-270, 271 Radar
BC-1271
Receiver, 100-156 MC, 12tubes
U/W BC-797,CH-205
P/O SCR-641
11-650
BC-1272
Control Box
U/W BC-463, CD-1000 to xfer ops to BC-462CB
P/O RC-56*
BC-1273
Relay Unit
U/W BC-1274 and RM-18
P/O SCR-561,572 Net Controls
BC-1274
Relay Unit
U/W BC-1273 and RM-18
"
"
"
"
"
"
BC-1275
Beacon Simulator
BC-1276*
X-Band Transmitter
8 tubes FT-481/MT-142
P/O SCR-667, APQ-10,13
BC-1277*
S-Band Signal Gen, 18tubes:
CD-956, CH-147, CX-265/U
S/T BC-1077
P/O IE-57B
BC-1278
Three-Antenna Sw-Box
U/W BC-787, AN-157, CD-1030-1032
P/O RC-154
BC-1279*
Short Gate ReceiverControl, 5 tubes
U/W BC-1252
BC-1280
Sig Gen and Oscilloscope in CH-285 U/WBC-1281
P/O SCR-658
1943
BC-1281*
Radar Rcvr 342-410 MC, 20MC IF
U/W BC-1280
P/O SCR-658
1943
BC-1281-T1 Radar Receiver, 397 MC
P/OSCR-685-T1 Radar Trainer
BC-1282*
Synchro Data Xmtr
BC-1283*
Synchro Receiver 5F
U/WPPI Unit BC-1239
P/O SCR-271
BC-1284
Preamplifier for BC-1269
P/O SCR-616
BC-1285*
Antenna Control Unit
U/W BC-1157 (MC-612 upgrade)
P/O SCR-717*
BC-1286*
AGC Unit
U/W BC-716, RA-49
P/O SCR-296 Coast Defence Radar
1943
BC-1287*
Scope, 3BP1 and 11 tubes
CH-157*
P/OIE-57, AN/APM-37
CW-60ACB
BC-1288
Frequency Meter, 470-493MC
U/W BC-663,664
P/O SCR-533 Radar-IFF
BC-1289
Preamplifier
BC-1290
Signal Generator, 550-2750 KC
U/W SCR-698 1 KW BC Xmtr.
BC-1291
Motor Control Box
BC-1292
PA Amp-Record Player
U/W CD-1074-1081, T-55
P/O PA-5
TM 11-2504
BC-1293*
Range-Azimuth Ind. 5CP1and 25 tubes
U/W RA-105
P/O CPX-1, RC-127,
RC-188,207,215,246,350, CPX-1
TM/TO #s
BC-1294
Modulator
BC-1295
Error IndicatorOscilloscope
U/W RA-108
P/O SCR-615 Radar
BC-1296
Range Control Unit
U/W BC-723 Range Unit, RS-296
P/O SCR-296
BC-1297
Position Xmitter. C/OPotentiometer RS-296, FT-336-A
P/O SCR-296
BC-1298
Interconnector
P/O RC-148 (mates SCR-268-C Radar to RC-148IFF)
BC-1299
RF Amplifier
P/ORC-267 Radar Training Device
BC-1300
Interphone Amplifier
U/W BC-366, BC-1307
P/O RC-36-A
BC-1301
Remote Control Unit(receiver)
P/O RC-261/SCR-619
BC-1302
Remote Control Unit (baseunit)
P/O RC-261/SCR-619
BC-1303
Control Unit
U/W SCR-522,542
CD-1170
P/O IE-36
11-509
1944
BC-1304
Oscillator, .8-3 KC (1S4, 12A5)
U/W FT-494, PN-26
P/O RC-163Beacon
BC-1305
Tuner for 20-40 MC FMXmtrs
U/W FT-493,495, ID-234, MP-67
P/O RC-163
BC-1306*
Field Radio 3.8-6.5 MC,CW-AM, 20 tubes
U/W AN-123,124,BG-173,175,
CD-1073,1086,1087, FT-482, GN-58, PE-237,ST-61
P/OSCR-694C
TM 11-694,4009
BC-1307
Control Box
U/W Interphone Amp BC-1300
BC-1308
....
BC-1309
Impulse Control Unit
BC-1310
Radar Receiver
90-120 MC
320 MC IF
P/O SCR-270,271
1943
BC-1311*
Amplifier
P/O AN/TRC-9
BC-1312
Master Control/4-Ch.Selector
U/W CD-1191, EE-8*
P/O SCR-624
BC-1313
Remote Control Box
S/T BC-1176
U/W CD-1191
P/O SCR-624
BC-1314
Remote Control Box
R/F BC-1171
U/W CD-1191, EE-8*
P/O SCR-624-A
BC-1315
Master Console
P/O RC-270 Radar Trainer
BC-1316
Console
BC-1317
Radar Receiver
31 MC IF
P/O RC-270 Radar Trainer
U/WBC-1315
1943
BC-1318
Receiver
BC-1319
Control Unit
BC-1320
Master Cathode Follower
BC-1321
Voltage Regulator
BC-1322
VHF Amplifier
U/W RC-181 Antenna
BC-1323*
Recorder, 3-Ch
9 tubes (913 CRT) U/W T-53
P/O GR-6-A
TM 11-2552
BC-1324
Noise Discrim.
U/WBC-406,412 (SCR-268)
P/O Mod-Kit MC-608
BC-1325
Noise Discrim. Kit
6H6,6AC7,6L6tubes
U/W BC-412/SCR-268
P/O MC-608
BC-1326
Sector Scan Unit
BC-1327
Modulator
BC-1328
Charging Transformer Unit
BC-1329
Transformer Unit
P/O SCR-615
BC-1330
Data Plotter
BC-1331
Range Data Xmtr
BC-1332
Marker Beacon Xmtr, 75 MC(improved BC-902)
CG-184/U
P/O RC-115*
BC-1333
Marker Beacon Rcvr, 75MC
24 VDC
BE-67, FT-161, IP-206
P/O RC-193
BC-1334
IF Amplifier, 36 MC, 1.5MC BW
in frame FM-51
BC-1335
Rcvr-Xmtr, 27-39 MC, 2 W, 4.3 MC IF, 120 Ch,Xtal Con. C/O: BB-54,
CD-1383, CH-291, FT-505, PE-219
P/O SCR-619
TM 11-879
BC-1336
Radio Set
SECRET
BC-1337
6-Channel Sound-Ranging Recorder(Teledeltos)
P/O GR-8
TM 11-2568
BC-1338
Bearing Ind.
U/W CD-1349-53, GN-59, MC-412,551, RC-295,P/O SCR-291
P/O MC-551,552 Bearing Indicator Kits
TM 11-2556
BC-1339
Noise Discrm. Kit
U/W CD-1346, RA-134
P/O SCR-682
BC-1340
Noise Discrm., 36 MC IF
U/WSCR-527
BC-1341
Antenna Hand Control Unit
P/O SCR-270-C
BC-1342
Antenna Control
U/W
RC-286
P/O SCR-720-C
BC-1343
Noise Discrm.
U/W CD-1325
P/O SCR-588 Radar
BC-1344
Noise Discrm. Kit
U/W CD-1326, CS-1088,
P/O SCR-588
BC-1345
Rcvr/Xmtr
P/O SCR-729 UHFBeacon
BC-1346
Audio Control-Amplifier
P/O PA-8
TM 11-2564
BC-1347
SCR-515 Xmtr, 750 KWPk U/WGA-11, I-243, M-417, MC-659, RA-28,129
BC-1348
Monitor Oscilloscope
U/W BC-1347
P/O SCR-615*
BC-1349
RF Unit, U/WBC-1347,1352,1358, MC-555,556,560, MP-88
P/O SCR-615*
BC-1350
Local Oscillator
P/OBC-1349/SCR-615*
BC-1351
Crystal Mixer
U/WMC-555,556
P/O BC-1349/SCR-615*
BC-1352
Preamplifier
P/O BC-1349/SCR-615
BC-1353
Console
U/W BC-1360 Console, P/OSCR-615*
BC-1354
Console
U/W MC-557 Computer
U/W BC-1360 Console. P/O SCR-615*
BC-1355
Azimuth-ElevationIndicator
U/W BC-1353 Console, P/OSCR-615*
BC-1356
Indicator Unit
U/W BC-1353 Console, P/O SCR-615*
BC-1357
Antenna Position Control
U/W MP-88, MC-392, BC-1353
P/O SCR-615*
BC-1358
Receiver, 2800 MC, 30 MCIF
U/W BC-1353 Console
P/O SCR-615*
BC-1359
Range Ind, 5"A/R-Scopes
U/W BC-1354, RA-131
P/O SCR-615*
BC-1360
Radar Control Console
U/W BC-1353,1354
P/O SCR-615*
BC-1361
Tank Interphone Box
U/WBC-1362
P/O RC-298
TM 11-702
BC-1362
External Tank IntercomBox
uses H-22 tel.
P/O RC-298
TM 11-703
BC-1363
Remote Indicator
3 Selsyns
U/WSCR-545,584 Radars
P/O MC-544
BC-1364
Radiosonde Rcvr-Ind., 392-413 MC, FM, 19 MCIF
P/O SCR-658
11-1158
BC-1365
B-Scope Track Display
U/W SCR-582,682A, CD-1358,1359
P/O MC-593
BC-1366*
Interphone Box (5-posSw)
P/ORC-36-*, AN/AIC-2
BC-1366M
Interphone Box for Lo-Z AIC-2A
BC-1367
Control Box
BC-1368
Control Unit
U/W SCR-602*
BC-1369
Interphone Box
BC-1370
PPI Control Unit
U/W BC-1092
P/O SCR-784 Radar
BC-1371
Range Indicator
2000/32000 Yd Scopes
S/T BC-1088
P/O SCR-784
BC-1372
Range Tracking Unit
410 KC
17 tubes
P/O SCR-784
BC-1373
Radar Transmitter
in Trailer K-84
P/O SCR-784
BC-1374
Klystron Oscillator
2000 MC
P/O BC-1373/SCR-784
BC-1375
Discriminator
BC-1376
PE-210 Control Box
U/WBC-191*
P/O SCR-177,188
BC-1377
DF Receiver, 545 KC - 44MC, 4 bands, 9 tubes
P/O SCR-197*
BC-1378
5" A-Scan Display
CD-1382, FM-93, RA-105
U/W SCR-784, RC-384
BC-1379
Receiver, 30-40 MC,FM
Vib PS
P/O SCR-298
BC-1380
Xmitter, 30-40 MC, FM
807 PA
P/OSCR-298
BC-1381
Video Amplifier-Discrim.,24.5 MC
U/W BC-1225,1339
P/O SCR-682
BC-1382
Rcvr-Xmtr
P/O SCR-682
BC-1383
Plotting Equipment Rack
U/W PN-52
P/O RC-294/SCR-584
BC-1384
DC Servo Amplifier
U/W BC-1383
P/O RC-294
BC-1385
Signal Monitor
U/W BC-779
P/OMRN-4
BC-1386
Receiver-Indicator-Synchronizer
P/OSCR-270
BC-1387
AN-190 Antenna Coupler
U/W MC-619 Homing Kit
P/O SCR-536
BC-1388
Phone Line Test Amplifier(WE 107A)
P/O TE-86
TM 11-2256,2556
1944
BC-1389
Timing Unit
P/O BC-1386
U/W SCR-270 Radar
BC-1390
Radar Receiver
P/O BC-1386
U/WSCR-270 Radar
BC-1391
Radar Receiver
"
"
"
"
BC-1392
Sweep Amplifier
BC-1393
RF Stabilizing Unit
P/O BC-1386
SCR-270
BC-1394
Remote Tuner Unit
U/W BC-1386
BC-1395
Frequency Divider
BC-1396
Driver Unit
BC-1397
Radar Rcvr-Xmitter
U/W MC-607, MP-61
P/O SCR-584/MC-607-A
BC-1398
Radar Rcvr, 8500-9600 MC,30/60 MC IF
P/O BC-1397
BC-1399
30 MC Video Amp.
U/WBC-1398, AN/MPG-2
P/O BC-584/MC-607
BC-1400
7" PPI Unit 70,000 Yd
RA-69PS
U/W AN/MPG-2*, BC-1401
P/O MC-607
BC-1401
Sweep Unit forBC-1400
U/W SCR-584, MPG-2*
P/O MC-607-A Mod. Kit
BC-1402
Radar Control Unit
U/W SCR-584
BC-1403
Range Indicator
P/O MC-627-A
BC-1404
Flight Simulator
P/O MC-627-A
BC-1405
Height Meter
P/OMC-627-A
U/W SCR-584*
BC-1406
Range Unit
P/O MC-627-A
U/W SCR-584*
BC-1407
Sector Scan Unit
BC-1408
Amplifier
BC-1409
Control Rack Unit
BC-1410
Data Unit
BC-1411
Control Unit
(last entry in SIG 5-1 for Feb., 1946)
BC-1412-1419 needed
BC-1420
Freq Mtr.
U/W BC-1421 100-150 MC Rcvr
P/ORC-256
TO AN-0810-227
BC-1421*
Receiver, 100-156 MC,AM,CW
Hazeltine, 11 tubes
P/O RC-256-C
BC-1500 Series...?
BC-1608
Receiver, 150-200 MC
110 VAC input
( Last-known BC- number. )
============================================================================
RETURNTO MENU |
|
樓主: VR2GY
