Semi-major axis 7 013 km
Perigee x apogee 592 x 677 km
Drag factor 0.000285920 1/ER
Mean Anomaly 90.167
Downlink
437.345MHz
Beacon 14.099MHz
Uplink
145.860MHz
Callsign
123456
TLE
(Updated November 28, 2013)
ZACUBE
1 39417U 13066B 13332.05077051 .00002723 00000-0 38040-3 0 259
2 39417 97.7999 44.4770 0061892 174.2611 185.9361 14.77128257 995
Telemetry
ZAcube-1 1k2 decode:
2013-11-21 09:11:07.750 UTC: [47 Bytes KISS Frame (without CRC)]
ctrl: 12 PID: F0 {I06^} 26 Payload Bytes
from 123456 to 012345:
1 > DC 0C 16 7A 61 63 75 62 65 30 31 2E 00 00 13 09 2C 0A DC 2C
21 > 06 7B 2C 0C 2E DC
Ü..zacube01.....,.Ü,.{,..Ü
It would be greatly appreciated if any received TLM be sent to (until we can get the decoder app up) the following email address: steenkampL [at] cput.ac.za.
|
|
